ALPHA WIRE 5855GR005 Hook-up Wire
The 5855 GR005 hook-up wire features a 22 AWG silver-plated copper conductor with green PTFE insulation, offering excellent flexibility and resistance to high temperatures and chemicals. Designed for industrial use, it withstands wear and abrasion while maintaining outstanding electrical properties. The wire's maximum pull tension is 5.9 lbs, with a nominal inductance of 0.04 µH per foot, and a DC resistance of 14 ohms per 1000 feet at 20°C. Operating temperature ranges from -60°C to 200°C, making it suitable for demanding environments and electrical circuits requiring durability and performance.
ALPHA WIRE 5855GR005 Hook-up Wire Specifications:
- Conductor Material: Silver-plated copper
- Conductor Size: 22 AWG
- Insulation Material: PTFE (Teflon)
- Insulation Wall Thickness: 0.010 inches
- Insulation Color: Green
- Maximum Pull Tension: 5.9 lbs
- Temperature Range: -60°C to 200°C
- Voltage Rating: 600 V
- Inductance: 0.04 µH per foot
- DC Resistance: 14 ohms per 1000 feet at 20°C
- Compliance: UL JAWM/STYLE 1213, VW-1, MIL-W-16878/4 (Type E) 200°C / 600 V
- Environmental Standards: RoHS 2011/65/EU, REACH, California Proposition 65
Buy the Buy AlphaWire Part Number 5855GR005 Online
Purchase the AlphaWire 5855GR005 hook-up wire online to enjoy reliable electrical performance with high-temperature resistance and chemical durability. Made of silver-plated copper with green PTFE insulation, it is ideal for industrial, aerospace, and electronic applications. This wire offers excellent flexibility, a maximum pull tension of 5.9 lbs, and can operate from -60°C to 200°C, ensuring durability in demanding environments. Order now to guarantee prompt delivery and exceptional quality for your electrical assemblies.
Order your AlphaWire 5855GR005 hook-up wire today and ensure your electrical projects benefit from high-performance, durable PTFE-insulated cable.
Frequently Asked Questions
Where can I buy ALPHA WIRE 5855GR005?
You can click on the BUY or RFQ button to purchase 5855GR005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 5855GR005?
You can download the 5855GR005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 5855GR005?
ALPHA WIRE
