ALPHA WIRE 6069CSL005 Shielded Control Cable
High-quality shielded cable designed for industrial and electronic applications, rated for 300 V and operating from -20°C to 80°C. Featuring multiple conductors with color-coded insulation, foil shielding, and PVC jackets, it ensures excellent electromagnetic interference (EMI) protection and reliability. Suitable for control wiring, instrumentation, and signal transmission, this cable complies with RoHS, CE, UL, and CSA standards, meeting environmental and safety regulations. Its construction includes 18 AWG conductors with precise twists, foil shields, and durable PVC insulation, making it ideal for demanding industrial environments and precise electrical tasks.
ALPHA WIRE 6069CSL005 Shielded Control Cable Specifications:
- Conductor Material: Copper
- Conductor Size: 18 AWG (16/30), 20 AWG (10/30), 16 AWG (10/30)
- Insulation: PVC, 0.016" wall thickness
- Shielding: Foil and drain wire
- Jacket: PVC, 0.063" wall thickness
- Temperature Range: -20°C to 80°C
- Voltage Rating: 300 V
- Mutual Capacitance: 57 pf/ft @1 kHz
- Ground Capacitance: 103 pf/ft @1 kHz
- Characteristic Impedance: 400 Ω
- Inductance: 0.18 μH/ft
- Conductor DCR: 8.6 Ω/1000ft
- Bend Radius: 10X cable diameter
- Maximum Pull Tension: 297 lbs
Buy the Buy AlphaWire 6069C Part Number 6069C Online
Get your AlphaWire 6069C shielded control cable today from our online store for fast delivery and guaranteed quality. Designed for industrial control and signal wiring, it features foil shielding, PVC insulation, and a 300 V rating. With excellent electrical properties, including low mutual capacitance and proper grounding, this cable offers durability and EMI protection. Perfect for demanding environments, it complies with RoHS, UL, CSA, and CE standards, making it the ideal choice for professional electrical installations. Buy online now and enhance your project’s reliability!
Order your AlphaWire 6069C shielded control cable today and ensure reliable signal transmission with superior EMI protection in demanding industrial environments.
Frequently Asked Questions
Where can I buy ALPHA WIRE 6069CSL005?
You can click on the BUY or RFQ button to purchase 6069CSL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 6069CSL005?
You can download the 6069CSL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 6069CSL005?
ALPHA WIRE
