ALPHA WIRE 652404SL005 Control Cable
Alpha Wire part number 652404 is a flexible control cable designed for reliable electrical connections in industrial and electronic applications. It features a 24 AWG bare copper conductor with a black insulation, a PVC jacket, and insulation that is oil resistant. The cable complies with IEC and UL standards, with a voltage rating of 600 V, and data on capacitance, inductance, and conductor resistance enhance its suitability for complex wiring needs. Suitable for static and dynamic environments, this cable offers flexibility, durability, and compliance with RoHS and REACH regulations, making it ideal for sophisticated electrical assemblies.
ALPHA WIRE 652404SL005 Control Cable Specifications:
- Conductor: 24 AWG Bare Copper
- Insulation: PVC, Oil Resistant, 0.022" Wall
- Jacket: PVC, 0.068" Diameter
- Voltage Rating: 600 V
- Temperature Range: -40 to 90°C (static), -5 to 90°C (dynamic)
- Bend Radius: 5X Cable Diameter
- Pull Tension: 14.1 Lbs
- Capacitance: 20.6 pF/ft @1 kHz
- Inductance: 0.24 μH/ft
- Conductor DCR: 23.9 Ω/000ft @20°C
- Lengths: 1000 FT, 500 FT, 100 FT spools, dimensions vary
- Standards: UL, CSA, CE, RoHS, REACH compliant
Buy the Buy Alpha Wire Part Number 652404 Online
Purchase the Alpha Wire 652404 control cable online for your industrial wiring needs. This high-quality cable features 24 AWG copper conductors, oil-resistant PVC insulation, and a durable PVC jacket. Rated at 600 V, it supports static and dynamic applications with excellent flexibility and mechanical strength. Compliant with RoHS and REACH regulations, it ensures environmentally friendly and safe electrical connections. Buy online now for fast delivery and to secure a reliable, high-performance cable for your electrical assemblies and control systems.
Order your Alpha Wire 652404 flexible control cable today and ensure your electrical projects meet the highest standards of reliability and safety.
Frequently Asked Questions
Where can I buy ALPHA WIRE 652404SL005?
You can click on the BUY or RFQ button to purchase 652404SL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 652404SL005?
You can download the 652404SL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 652404SL005?
ALPHA WIRE
