ALPHA WIRE 65263CYSL005 Control Cable
This high-quality control cable features a flexible design with three 26 AWG bare copper conductors, insulated with PVC walls. It is oil resistant, with an external slate PVC jacket, designed for industrial control and automation applications. The cable has a shield and drainage layer, with overall UV and oil resistance, suitable for environments demanding durability. Rated for 600V, it operates between -40°C to 90°C, with a minimum bend radius of 8 times its diameter, ensuring reliable performance in challenging conditions. Its construction complies with UL, CSA, and CE standards, making it an ideal choice for demanding control systems.
ALPHA WIRE 65263CYSL005 Control Cable Specifications:
- Conductor: 26 AWG Bare Copper, Ø0.019 inches
- Insulation Wall: 0.022 inches PVC
- Jacket Wall: 0.030 inches PVC, Slate color, Oil resistant
- Shield: Tinned Copper Braid, 85% coverage
- Outer Jacket: 0.035 inches PVC, Slate, Oil resistant, tissue tape separator
- Voltage Rating: 600 V
- Temperature Range: -40°C to 90°C static, -5°C to 90°C dynamic
- Bend Radius: 8X cable diameter
- Pull Tension: 13.1 lbs maximum
- Capacitance: 24.2 pF/ft @1 kHz, Ground Capacitance: 44 pF/ft @1 kHz
- Inductance: 0.26 μH/ft
- Conductor Resistance: 38 Ω/1000 ft @20°C
- Shield Resistance: 3 Ω/1000 ft @20°C
- Cable Lengths: 1000 ft, 500 ft, 100 ft options with varying dimensions
- Standards: UL, CSA, CE compliant, RoHS 2 and RoHS 3 compliant
- Environmental: Suitable for use at temperatures from -40°C to 90°C with a minimum bend radius of 8 times the diameter
Buy the Alpha Wire 65263CY – Reliable Control Cable for Industrial Applications
Order the Alpha Wire control cable 65263CY now to ensure your industrial control and automation systems operate with maximum reliability. This high-quality cable features three 26 AWG copper conductors with PVC insulation and a durable PVC jacket in slate color, offering excellent oil and environmental resistance. Certified with UL, CSA, and CE standards, it supports maximum operation at 600V and temperatures from -40°C to 90°C. With flexible construction, shielded design, and various lengths available, this control cable guarantees dependable performance in demanding industrial environments.
Buy Alpha Wire 65263CY now and experience unmatched durability, oil resistance, and reliable performance in control and automation systems.
Frequently Asked Questions
Where can I buy ALPHA WIRE 65263CYSL005?
You can click on the BUY or RFQ button to purchase 65263CYSL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 65263CYSL005?
You can download the 65263CYSL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 65263CYSL005?
ALPHA WIRE
