ALPHA WIRE 65825SL005 Control Cable
The 65825 SL005 is a versatile 25-conductor unshielded control cable with 18 AWG copper conductors and a durable oil-resistant slate PVC jacket. Designed for demanding environments, it features tissue tape separator, rounded geometry for liquid-tight IP67 or NEMA 6 standards, and excellent EMI resistance via Supra-Shield® technology. Suitable for high-flex, torsion, and continuous-flex applications like motion control and robotics, it supports a maximum pull tension of 314 lbs, a capacitance of 30 pF/ft at 1 kHz, and an inductance of 0.19 µH/ft. The cable operates effectively in temperatures from -40°C to 90°C, ensuring reliable performance in industrial settings.
ALPHA WIRE 65825SL005 Control Cable Specifications:
- Conductor: 18 AWG bare copper, 16/30 construction
- Insulation: 0.022 inch PVC wall, oil resistant
- Jacket: 0.050 inch slate PVC, with tissue tape separator
- Diameter: approximately 0.666 inch with ±0.037 inch tolerance
- Operating temperature: -40°C to 90°C (static), -5°C to 90°C (dynamic)
- Bend radius: 5 times cable diameter
- Maximum pull tension: 314 lbs
- Voltage rating: 600 V
- Capacitance: 30 pF/ft at 1 kHz
- Inductance: 0.19 µH/ft
- Conductor DCR: 6.8 Ω/1000 ft @20°C
- Certifications: UL, CSA, VDE, CE, RoHS
- Lengths: 100 ft, 200 ft, and custom spools available
Buy the Alpha Wire Series 711 Control Cable: 65825SL005
Purchase the Alpha Wire Series 711 65825SL005 control cable online today to benefit from its exceptional flexibility, high durability, and reliable EMI performance. Designed with 18 AWG copper conductors and an oil-resistant PVC jacket, this high-performance cable supports demanding industrial applications such as robotics and motion control. Its rounded geometry guarantees liquid-tight IP67 or NEMA 6 compliance, ensuring protection against dust and water ingress. With a maximum pull tension of 314 lbs, and operating from -40°C to 90°C, it ensures dependable, long-lasting operation in challenging environments. Buy now for fast delivery and guaranteed quality.
Order your Alpha Wire Series 711 65825SL005 control cable today and ensure high flexibility and durable performance in industrial automation and motion control applications.
Frequently Asked Questions
Where can I buy ALPHA WIRE 65825SL005?
You can click on the BUY or RFQ button to purchase 65825SL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 65825SL005?
You can download the 65825SL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 65825SL005?
ALPHA WIRE
