ALPHA WIRE F105116BK005 Heat Shrink Tubing
The F1051/16 BK005 is a black heat shrink tubing made of irradiated PVC. It features a 2:1 shrink ratio and has a minimum tensile strength of 3000 psi. The tubing provides a minimum dielectric strength of 1083 volts per mil. It shrinks to its full size at a minimum temperature of 105°C and has a minimum shrink temperature of 100°C. It is suitable for applications in safety and industrial environments and operates within a temperature range of -20°C to 105°C.
ALPHA WIRE F105116BK005 Heat Shrink Tubing Specifications:
- Material: Irradiated PVC
- Color: Black
- Minimum Recovered ID: 0.031 inches
- Minimum Supplied ID: 0.062 inches
- Wall Thickness: 0.020 inches
- Shrink Ratio: Approximately 2:1
- Full Recovery Temperature: 105°C
- Minimum Shrink Temperature: 100°C
- Tensile Strength: 3000 psi, Min ASTM D638
- Elongation: 300%, Min ASTM D638
- Dielectric Strength: 1083 V/mil, Min ASTM D876
- Temperature Range: -20°C to 105°C
- Shelf Life: 1 Year at 18 to 35°C
Buy the AlphaWire Series Heat Shrink Tubing: F105116BK005
Order AlphaWire F105116BK005 heat shrink tubing online today. This high-quality irradiated PVC tubing with a 2:1 shrink ratio offers excellent electrical insulation, tensile strength, and temperature resistance from -20°C to 105°C. Ideal for protecting wires, cables, and connections in industrial, automotive, and electronic applications. Its full recovery at 105°C ensures reliable performance. Purchase now for long-lasting insulation, safe operation, and efficient assembly processes, all delivered directly to your door with ease.
Get AlphaWire F105116BK005 heat shrink tubing today—designed for insulation, protection, and durability in electrical and industrial applications.
