ALPHA WIRE F321V14WH003 Heat Shrink Tubing
The F321V-1/4 heat shrinkable tubing from Alpha Wire features cross-linked material with a recoverable inner diameter of 0.080 inches and a wall thickness of 0.028 inches. Designed for electrical insulation, its high-temperature resistance ranges from -55°C to 135°C, with a shrink ratio suitable for various wiring applications. Constructed to meet UL 224, CSA standards, and RoHS compliant, this tubing ensures excellent chemical, mechanical, and dielectric properties. Its durable, low-fire, flame-retardant construction makes it ideal for insulation and protection in electrical and electronic systems.
ALPHA WIRE F321V14WH003 Heat Shrink Tubing Specifications:
- Outer diameter: Min 0.240 in, Max 0.080 in recovered ID
- Wall Thickness: 0.028 in nominal
- Colors: Black, White
- Temperature Range: -55°C to 135°C
- Shrink Ratio: Not specified
- Minimum Shrink Temperature: Not specified
- Dielectric Strength: 500 V/mil
- Volume Resistivity: 1x10^14 ohm-cm
- Tensile Strength: 200%, minimum TM D638
- Elongation at Break: 100%, minimum TM D638
- Shelf Life: 25 years at 18-35°C
- Flammability: UL 94V-0, VW-1
- Environmental Compliance: RoHS, REACH, California Proposition 65
- Material: Cross-linked polyolefin
- Certifications: UL, CSA
- Packaging: 250 FT
- Other colors available upon request
Buy the Alpha Wire Series F321 Heat Shrink Tubing: F321V-1/4
Enhance your electrical insulation and protection with Alpha Wire's F321V-1/4 heat shrink tubing. This cross-linked polyolefin tubing offers a recoverable inner diameter of 0.080 inches, a wall thickness of 0.028 inches, and operates within a temperature range of -55°C to 135°C. Suitable for diverse wiring, cable insulation, and electronic systems, it complies with UL, CSA, and RoHS standards. Ensure superior durability, chemical resistance, and flame retardance by purchasing online today for your electrical and electronic needs.
Buy Alpha Wire F321V-1/4 heat shrink tubing now and experience unmatched reliability, excellent electrical insulation, and high-temperature resistance for wiring projects.
