ALPHA WIRE PMC16SL080 waterproof cable gland
The PMC16 SL080 Fit® Standard Dome Design Metric Cable Gland offers premium cable strain relief and environmental protection. It is dust-, dirt-, and sand-resistant, as well as watertight with an IP68 rating, providing protection against water ingress in demanding environments. The gland includes a locknut and gasket for a complete sealing solution. Made from high-strength polyamide 6 in a slate RAL 7001 color, it features robust rubber seals to prevent water entry under pressure. The device is rated for protection class IP68 (5 bar, 30 minutes) and IP66, with flammability rated UL94V-2. It operates within a temperature range of -20°C to +100°C permanently, and -30°C to +150°C intermittently. The cable gland is UL listed (514) and CSA certified (C22). It is suitable for use in industrial automation, electrical installations, and renewable energy applications.
ALPHA WIRE PMC16SL080 waterproof cable gland Specifications:
- Material: Polyamide 6 (PA 6)
- Color: RAL 7001 (Slate Grey)
- Protection Class: IP68 (5 bar, 30 min), IP66
- Flammability: UL94V-2
- Temperature Range: -20°C to +100°C (permanent), -30°C to +150°C (intermittent)
- Thread Type: Metric according to EN 60423
- Thread Size Options: M-12x1.5, M-16x1.5, M-20x1.5, M-25x1.5, M-32x1.5, M-40x1.5
- Sealing: Rubber gasket, locknut included
- Approvals: UL 514, CSA C22.2
- Standard Package: 10 glands per package
Buy the Alpha Wire PMC16SL080 U– Reliable Waterproof Cable Gland for Industrial Applications
Order the Alpha Wire waterproof cable gland online today and enhance your electrical installations with premium IP68 protection. This high-quality polyamide gland ensures excellent sealing against dust, dirt, and water ingress while providing reliable strain relief in challenging environments. Suitable for industrial automation, renewable energy systems, and electrical equipment, it features a durable rubber gasket and robust construction. Simplify your procurement process and secure your applications with this UL listed and CSA certified waterproof cable gland, available for fast online purchase.
Buy Alpha Wire PMC16SL080 now and experience unmatched waterproofing and robust sealing for demanding industrial environments.
Frequently Asked Questions
Where can I buy ALPHA WIRE PMC16SL080?
You can click on the BUY or RFQ button to purchase PMC16SL080 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part PMC16SL080?
You can download the PMC16SL080 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of PMC16SL080?
ALPHA WIRE
