ALPHA WIRE SW30NA008 Spiral Wrap Tubing
The SW30 NA008 spiral wrap tubing is made of high-quality PTFE, offering excellent thermal and chemical resistance. It simplifies wire harnessing, bundling, and cabling in industrial settings, eliminating the need for installation tools. Its flexible design allows it to wrap tightly around wires, even around sharp edges, providing secure and organized cable management. This tubing features a right-hand pitch, UL VW-1 flammability rating, and can withstand tensile forces up to 3000 PSI, making it ideal for demanding environments requiring reliable insulation and protection.
ALPHA WIRE SW30NA008 Spiral Wrap Tubing Specifications:
- Material: PTFE
- Color: Natural / Black
- Outside Diameter: 0.125" +/- 0.010"
- Inside Diameter: 0.065" Nominal
- Wall Thickness: 0.030" Nominal
- Pitch: 0.187" Nominal
- Pitch Direction: Right Hand
- Flammability: UL VW-1
- Temperature Rating: -268°C to +260°C
- Tensile Strength: 3000 PSI
- Applicable Standards: ASTM D-3295-01, group 4; UL CCN UZKX2
- Package Lengths: 25 ft or 100 ft options, with maximum 3 lengths per package, minimum length 10 ft
Buy the Alpha Wire SW30 – Reliable Spiral Wrap Tubing for Industrial Applications
Purchase the Alpha Wire SW30 spiral wrap tubing online today to enjoy high-quality PTFE protection for cables and wires. This flexible, heat-resistant tubing is ideal for bundling and organizing wiring in industrial environments. Its UL VW-1 flammability rating ensures safety, while its high tensile strength guarantees durability under demanding conditions. Easy to install without tools, it provides excellent protection against abrasion, chemicals, and temperature extremes from -268°C to +260°C. Order now for fast, reliable delivery and enhance your wiring system's performance and safety.
Buy Alpha Wire SW30 spiral wrap tubing now and ensure reliable cable management with high heat resistance and flexible PTFE protection for industrial use.
Frequently Asked Questions
Where can I buy ALPHA WIRE SW30NA008?
You can click on the BUY or RFQ button to purchase SW30NA008 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part SW30NA008?
You can download the SW30NA008 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of SW30NA008?
ALPHA WIRE
