AMPHENOL COMMERCIAL PRODUCTS L717DE09PF179 Subminiature Circular Connector
The Amphenol Commercial Products L717DE09PF179 is a subminiature circular connector designed for demanding applications. Its steel shell provides robust protection, while the tinned finish ensures reliable signal transmission. The glass-filled thermoplastic body offers excellent flame retardancy (UL 94 V-O). This connector is suitable for use in various industrial environments where space is limited and a secure connection is critical. It is designed to meet climatic specifications outlined in NF C 93-425, sheet HE501, and MIL C 24-308.
AMPHENOL COMMERCIAL PRODUCTS L717DE09PF179 Subminiature Circular Connector Specifications:
- Shell Material: Steel
- Shell Finish: Tinned
- Body Material: Glass filled thermoplastic
- Flame Retardancy: UL 94 V-O
- Contact Material (Sockets): Brass
- Contact Finish: Gold over Ni
- Voltage Proof: >1000 V Rms to 50Hz
- Nominal Current (size20): 7.5 A
- Nominal Current (size8): 20 A
- Contact Resistance: <5 m Ohms
- Temperature Range: -55°C up to 85°C
- Mating Force (size E): 30 N max, 3.5 N mini
- Mating Force (size A): 50 N max, 4.4 N mini
- Mating Force (size F): 83 N max, 8.0 N mini
- Mating Force (size C): 123 N max, 11.0 N mini
- Mating Force (size D): 166 N max, 14.5 N mini
- Contact Type (S): Female
- Contact Type (P): Male
- Mounting Type Configuration: X: Without
- Wire Wrap: with Dimples. plug only
