AMPHENOL INDUSTRIAL PT06E1412P Miniature Circular Connector
The PT06E-14-12P from Amphenol is a MIL-DTL-26482 Series I equivalent straight plug connector featuring 12 contacts. Part of the PT series, these miniature cylindrical connectors provide high-density contact arrangements within a circular shell. Designed for harsh environments, they are resistant to salt spray exposure up to 48 or 500 hours and are built to withstand extreme shock, vibration, and exposure conditions. The connectors feature a quick disconnect bayonet coupling for rapid mating and unmating, with a 5-key/keyway polarization and a 3-point bayonet lock to ensure positive, cross-polarization-free connection. Spring tension maintained by a wave washer in the coupling nut preserves the interfacial seal between halves. Constructed with an aluminum alloy body with olive drab chromate over cadmium plating, and copper alloy solder pin contacts with gold plating, they are suitable for environmental sealing and pressurized applications. These connectors are intermateable, intermountable, and interchangeable with other MIL-DTL-26482 connectors and support up to 500 mating cycles. Operating temperature ranges from -55°C to +125°C. They are UL recognized (file E115497) with an insulation resistance of 5000 MΩ at 25°C.
AMPHENOL INDUSTRIAL PT06E1412P Miniature Circular Connector Specifications:
- Shell Material: Aluminum alloy with olive drab chromate over cadmium plating
- Contact Material: Copper alloy, gold plated
- Number of Contacts: 12
- Contact Size: 20 (pin and socket)
- Contact Resistance: Less than 5 milliohms (initial)
- Insulation Resistance: 5000 MΩ at 25°C
- Operating Temperature Range: -55°C to +125°C
- Salt Spray Resistance: Up to 500 hours
- Vibration and Shock Resistance: Exceeds MIL-STD-202
- Waterproof & Environmental Seal: Yes
- Mating Cycles: Supports up to 500 cycles
- Coupling: 3-point bayonet with 5-key/keyway polarization
- Seal: Resilient gaskets and wave washer in coupling nut
- UL Recognition: Yes (File E115497)
- Maximum Voltage: 500 VAC RMS
- Current Rating: 13 A per contact
- Dielectric Withstanding Voltage: 1500 V RMS
- Temperature: From -55°C to +125°C
Buy the Amphenol Series MIL-C Connector: PT06E 14-12P
Order the Amphenol PT06E 14-12P miniature circular connector online today. Designed for rugged applications, it features high density 12 contacts, environmentally sealed, and quick bayonet coupling. Perfect for harsh environments with resistance to salt spray, vibration, and extreme temperatures. Supports up to 500 mating cycles, ensuring durability in aerospace, military, and industrial uses. Trust Amphenol’s quality and reliability for your critical connections. Purchase securely online and enjoy fast delivery and expert support.
Get Amphenol PT06E 14-12P today—built for harsh environments, providing reliable, high-density connections with quick bayonet coupling.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL PT06E1412P?
You can click on the BUY or RFQ button to purchase PT06E1412P from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part PT06E1412P?
You can download the PT06E1412P datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of PT06E1412P?
AMPHENOL INDUSTRIAL
