AMPHENOL LTD 62GB12E1608SN Miniature Bayonet Lock Connector
The 62GB Series connector is a miniature bayonet lock solution compliant with military standards MIL-C-26482. Made of brass or stainless steel with corrosion-resistant zinc cobalt olive drab finish, it offers high reliability for military and industrial use. The connector features gold-plated solder contacts, insulative polychloroprene inserts, and positive keying to prevent mis-mating. Available configurations include box, cable, and hermetic types with various mounting options like flange and single hole. Suitable for applications demanding robust performance at -55°C to 125°C, high altitudes, and in corrosive environments.
AMPHENOL LTD 62GB12E1608SN Miniature Bayonet Lock Connector Specifications:
- Material: Brass or Stainless Steel shells with Zinc cobalt olive drab finish, optional cadmium plating
- Contacts: Gold-plated solder type, copper alloy base
- Temperature Range: -55°C to +125°C
- Insert: Polychloroprene rubber, insulative properties
- Pin Contacts: Size 20, rated to 7.5A; Size 16, rated to 13A
- Shell Sizes: From 8 (Shell diameter ~12.7mm) up to 24 (Shell diameter ~36.1mm)
- Voltage Rating: Up to 2100V DC Peak at sea level, derated for altitude
- Mechanical: Bayonet coupling, positive keying with multiple orientations (A-F)
- Sealing: Hermetic glass sealed dielectric available in hermetic variants
- Finish: Zinc cobalt olive drab standard, others on request
- Compliance: MIL-C-26482E, certified, and used globally in defense and industrial sectors
Buy the Amphenol Series 62GB Bayonet Lock Connectors: 62GB12E1608SN
Purchase the rugged and reliable Amphenol Series 62GB connector online today. Ideal for demanding industrial and military applications, it features corrosion-resistant shells, gold-plated solder contacts, and multiple mounting options. Designed to operate efficiently from -55°C to +125°C, it provides excellent performance at high altitudes and in harsh environments. With a compact size and seal integrity, this connector ensures secure, mis-mating resistant connections, supporting your mission-critical projects with trusted durability and secure contacts.
Order your Amphenol Series 62GB12E1608SN high-reliability connector today and enhance your project’s durability with proven military-grade quality.
Frequently Asked Questions
Where can I buy AMPHENOL LTD 62GB12E1608SN?
You can click on the BUY or RFQ button to purchase 62GB12E1608SN from an authorized AMPHENOL LTD distributor.
How do I troubleshoot issues or seek technical support for part 62GB12E1608SN?
You can download the 62GB12E1608SN datasheet or visit the AMPHENOL LTD website for support.
Who is the manufacturer of 62GB12E1608SN?
AMPHENOL LTD
