AMPHENOL LTD 62GB81210 Miniature Bayonet Lock Connector
The 62GB Series connectors are miniature bayonet lock connectors complying with MIL-C-26482 standards, suitable for military and industrial applications. Constructed from brass or stainless steel with high corrosion resistance, they feature gold-plated contacts for soldered connections. The series offers a range of configurations, finishes, and insertion types including hermetic and non-hermetic models. Designed to operate from -55°C to 125°C, they include comprehensive features such as keying, rotate-in inserts, and various mounting styles—box, cable, and single-hole. Their robust construction ensures excellent electrical performance, sealing, and durability for demanding environments, including high altitude and high temperature conditions.
AMPHENOL LTD 62GB81210 Miniature Bayonet Lock Connector Specifications:
- Material: Brass or stainless steel shells, zinc cobalt olive drab finish (other finishes available, e.g., cadmium plate by special order)
- Insert Material: Polychloroprene rubber, gold-plated contacts for soldered connections
- Operating Temperature Range: -55°C to +125°C
- Shell Finish: Zinc cobalt olive drab (standard), optional cadmium plate
- Contact Rating: Size 20 contacts rated up to 7.5 A; size 16 rated up to 13 A; according to contact size and configuration
- Voltage Rating: Up to 1500 V (nominal) depending on model and altitude derating
- Altitude Operation: Up to 27,900 ft (8500 m); voltage and current derating applied at high altitudes
- Connection Type: Solder, pin, or socket contacts, gold plated for durability
- Sealing: Hermetic glass sealed dielectric & gasket seals for various environmental conditions
- Keying: Shell-to-shell keying with multiple orientations (N, B, C, E, F), anti-mismatch features
- Mounting Styles: Box, cable, single-hole, flange, and hermetic mounts
- Mechanical: Bayonet coupling with high retention force, suitable for critical applications
- Durability: Designed for 500+ mating cycles, impact, vibration, and temperature resilience
- Certifications: Compliant with MIL-C-26482E standard, certified and tested per military specifications
Buy the Amphenol 62GB – Reliable Military Connectors for Industrial Applications
Order Amphenol 62GB series miniature bayonet lock connectors online today and ensure dependable electrical connections for military and industrial use. These connectors are engineered to withstand extreme temperatures, corrosion, and high altitudes, with robust sealing and high-current ratings. Their versatile mounting options, keying features, and certified performance make them ideal for demanding applications. Experience quick, secure mating with durable materials and exceptional electrical integrity. Purchase now to benefit from competitive pricing and reliable delivery, ensuring your project stays on schedule with high-quality connectivity solutions.
Buy Amphenol 62GB connectors now and experience unmatched reliability and performance in demanding environmental conditions.
Frequently Asked Questions
Where can I buy AMPHENOL LTD 62GB81210?
You can click on the BUY or RFQ button to purchase 62GB81210 from an authorized AMPHENOL LTD distributor.
How do I troubleshoot issues or seek technical support for part 62GB81210?
You can download the 62GB81210 datasheet or visit the AMPHENOL LTD website for support.
Who is the manufacturer of 62GB81210?
AMPHENOL LTD
