AMS OSRAM GROUP SPLPL90 Pulsed Laser Diode
The SPLPL90 from Osram is a compact pulsed laser diode housed in a plastic package. It delivers up to 25W peak power at 905 nm wavelength, suitable for short pulses from 1 to 100 ns. Designed for high-volume applications, it features a 200 µm by 2 µm aperture, operates at a maximum forward current of 40A, and functions across a temperature range of -40°C to 85°C. Ideal for range finders, traffic surveillance, and professional laser sensors, offering reliable performance in diverse industrial systems.
AMS OSRAM GROUP SPLPL90 Pulsed Laser Diode Specifications:
- Peak wavelength: 905 nm
- Peak optical power: 25 W
- Laser aperture: 200 µm x 2 µm
- Forward current: 40 A
- Operating temperature range: -40°C to 85°C
- Pulse width: 1 ns to 100 ns
- Spectral width: 7 nm
- Spectral emission peak: 895 to 915 nm
- Output power: 20 to 30 W (typical 25 W)
- Threshold current: 0.75 A
- Operating voltage: 43 V (typical 43 V)
- Rise and fall time: 1 ns
- Thermal resistance: 160 K/W
- Dimensions: Package size with aperture 200 µm x 2 µm
- Soldering temperature: 260°C
Buy the OSRAM Series SPLPL90 Pulsed Laser Diode: SPLPL90
Experience high-performance laser technology with OSRAM SPLPL90, a pulsed laser diode offering up to 25W peak power at 905 nm. Designed in a cost-effective plastic package, it provides short pulses from 1 to 100 ns, perfect for range finders, traffic monitoring, and professional laser sensors. Its robust thermal and electrical characteristics ensure durability in diverse industrial environments. Ideal for high-volume production, this diode combines reliability, compactness, and precision, making it an essential component for advanced laser systems and automation solutions.
Get OSRAM SPLPL90 laser diode today—built for precision, high peak power, and reliable short pulse operation in demanding laser applications.
Frequently Asked Questions
Where can I buy AMS OSRAM GROUP SPLPL90?
You can click on the BUY or RFQ button to purchase SPLPL90 from an authorized AMS OSRAM GROUP distributor.
How do I troubleshoot issues or seek technical support for part SPLPL90?
You can download the SPLPL90 datasheet or visit the AMS OSRAM GROUP website for support.
Who is the manufacturer of SPLPL90?
AMS OSRAM GROUP
