Advantech Automation BBWCDTM2M Industrial Wireless Sensor
The Wzzard Mesh Wireless Sensor is an industrial-grade device designed for reliable industrial applications. It features ultra-low power 802.15.4e SmartMesh IP technology, ensuring up to 99.999% connectivity in RF demanding environments. The sensor supports multiple external industry-standard analog and digital sensors via M12 connectors or conduit fittings, with internal temperature sensing. Its rugged, IP67-rated fiber-reinforced polyester enclosure allows deployment in harsh conditions. It offers secure communication with AES encryption, self-configuring mesh networking, and easy installation, making it ideal for HVAC, power monitoring, and industrial automation.
Advantech Automation BBWCDTM2M Industrial Wireless Sensor Specifications:
- Power: Internal (2) 3.6V 2400 mAH Lithium Thionyl Chloride AA Batteries, Battery Life >5 years; Optional external 10-30 VDC @ 40mA
- Sensors: Supports analog (0-10 VDC, 4-20 mA), digital, thermocouple (J, K, N, R, S, T, B, E), thermistor (10K NTC), integrated temperature sensor
- Wireless: 802.15.4e SmartMesh IP, Frequency Band 2.400–2.4835 GHz, 15 channels, Data Rate 250 kbps, Indoor Range 100m, Outdoor Range 300m, Output Power 8 dBm
- Connectivity: M12 connector, conduit fitting, RP-SMA Omni-directional antenna (3.8 dBi), IP67 enclosure, dimensions 194mm, weight 0.34kg
- Operating Conditions: Temperature -40°C to 80°C, Humidity 0-95%, Storage -40°C to 85°C, Certifications include RoHS, WEEE, FCC, EN standards
- Security: 128-bit AES encryption, message integrity, dynamic key rotation, device authentication
- Installation: Indoor/outdoor, magnetic mount, mounting ears, screws, rugged housing suitable for demanding environments
Buy the Advantech Series BB-WSD2x Wireless Sensor: BB-WSD2M3101P2K
Experience reliable industrial monitoring with the Advantech Series BB-WSD2M3101P2K wireless sensor, featuring ultra-low power mesh networking, rugged IP67 enclosure, multiple sensor interfaces, and secure AES encryption. Designed for demanding environments, it supports analog, digital, thermocouple, and thermistor sensors, with easy mounting options for indoor and outdoor applications. This robust sensor ensures long battery life over five years, providing seamless connectivity, easy configuration, and self-healing mesh networks to optimize your industrial automation, HVAC, and power monitoring projects effectively.
Order your Advantech Series BB-WSD2M3101P2K wireless sensor today and ensure reliable, secure industrial monitoring in harsh environments.
Frequently Asked Questions
Where can I buy Advantech Automation BBWCDTM2M?
You can click on the BUY or RFQ button to purchase BBWCDTM2M from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part BBWCDTM2M?
You can download the BBWCDTM2M datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of BBWCDTM2M?
Advantech Automation
