ALPHA WIRE 1857GR005 Hook-up Wire
The 1857 GR005 is a 100-foot green hook-up wire featuring a tinned copper conductor with PVC insulation. Designed for control cabinets in protected environments, it is suitable for machine tools, high-temperature ovens, or off-road construction equipment. It provides excellent resistance to wear, abrasion, oil, solvents, and chemicals, ensuring reliable electrical performance under demanding conditions. With a maximum pull tension of 13.9 lbs, a nominal inductance of 0.04 µH/ft, and operational temperature range from -55°C to 105°C, this versatile wire is ideal for defense, military, aerospace, and industrial applications.
ALPHA WIRE 1857GR005 Hook-up Wire Specifications:
- Conductor: Tinned copper, 18 AWG (7/26) TC
- Insulation: PVC, 0.010 inch wall thickness
- Color: Green
- Length: 100 feet (also available in 10 and 1000 ft lengths)
- Temperature Range: -55°C to 105°C
- Voltage Rating: 600 V
- Maximum Pull Tension: 13.9 lbs
- Inductance: 0.04 µH/ft
- Conductor Resistance: 6.3 Ω/1000 ft @ 20°C
- Applicable Standards: MIL-W-16878E/1, RoHS 2, REACH, California Proposition 65
- Physical Dimensions: 6.5x4x2.5 inches (spool), 2.75x2x1.125 inches (shorter spool)
Buy the AlphaWire Series Hook-up Wire: 1857GR005
Purchase the AlphaWire Series 1857GR005 hook-up wire online today and enjoy fast, secure delivery. This 100-foot green wire with PVC insulation and tinned copper conductor is perfect for control cabinets, machinery, high-temperature environments, and industrial use. Designed to withstand harsh conditions, it features excellent resistance to wear, oils, and chemicals. With a temperature range from -55°C to 105°C and a voltage rating of 600 V, it provides reliable electrical performance. Ideal for defense, aerospace, and manufacturing sectors, purchase now for quality assurance.
Order your AlphaWire Series 1857GR005 premium hook-up wire today and ensure reliable electrical connections in critical control and industrial applications.
Frequently Asked Questions
Where can I buy ALPHA WIRE 1857GR005?
You can click on the BUY or RFQ button to purchase 1857GR005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 1857GR005?
You can download the 1857GR005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 1857GR005?
ALPHA WIRE
