ALPHA WIRE 28411BLUE100 Hook-Up Wire
The ALPHA WIRE 2841/1-BLUE-100 is a versatile hook-up wire suitable for a variety of industrial applications. Constructed with 30 AWG solid SPC conductor and a durable PTFE insulation, this wire provides excellent electrical performance and resistance to harsh environments. It boasts a wide operating temperature range (-60°C to 200°C) and is compliant with RoHS directives, making it a reliable choice for modern electronic systems. Commonly used in automotive, aerospace, and industrial control systems, this wire ensures dependable signal transmission and power delivery.
ALPHA WIRE 28411BLUE100 Hook-Up Wire Specifications:
- Component 1: 1 X 1 HOOKUP
- Conductor: 30 (SOLID) AWG SPC
- Insulation Wall: 0.006" Nom. PTFE
- Insulation Diameter: 0.022+/- 0.002
- Colors: WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN, ORANGE, SLATE, VIOLET
- Military Specification: MIL-W-16878/6 (Type ET)
- Other Specification: NEMA HP3-ETXBBA
- Temperature Range: -60 to 200°C
- Bend Radius: 10X Cable Diameter
- Pull Tension: 0.79 Lbs, Maximum
- Voltage Rating: 250 VRMS
- Inductance: 0.06 µH/ft, Nominal
- Conductor DCR: 104 Ω/1000ft @20°C, Nominal
- Packaging Flange x Traverse x Barrel: 2.75 x 2 x 1.125 Max. (3 separate pieces; Min length/piece 100 FT)
- Packaging 100 FT: 2.75 x 1 x 1.125 Continuous length
- RoHS Compliance: Compliant commencing with 3/1/2005 production
- SVHC Declaration: Does not contain SVHC in excess of 0.1% mass
