ALPHA WIRE 470041YYGE321 Industrial Control Cable
Pro-Met unshielded flexible industrial control cable with four 17 AWG bare copper conductors and a gray PVC jacket, ideal for demanding environments such as food, medical, industrial automation, automotive, defense, and aerospace. This oil-resistant, UV-stable cable withstands tough conditions, including continuous flexing up to 1 million cycles. Operating within -30°C to +70°C dynamically and -40°C to +80°C statically, it offers excellent flexibility. The cable's bend radius is 10x its outer diameter for occasional movement and 6x for fixed installation, ensuring safe, reliable performance in harsh environments.
ALPHA WIRE 470041YYGE321 Industrial Control Cable Specifications:
- Number of conductors: 4
- Conductor size: 17 AWG
- Conductor Material: Bare Copper
- Jacket Material: PVC
- Jacket Color: Gray (RAL 7001)
- Temperature Range: -40°C to +80°C (static), -30°C to +70°C (dynamic)
- Bend Radius: 10x outer diameter (occasional flex), 6x outer diameter (fixed)
- Flex Life: Up to 1,000,000 cycles
- Resistance: Yes
- Oil Resistance: Yes
- UV Resistance: Yes
Buy the Alpha Wire Series Control Cable: 470041YYGE321
Order Alpha Wire 470041YYGE321 control cable online today and benefit from superior flexibility, oil and UV resistance, and reliable performance in challenging environments. Designed for demanding industrial automation, medical, automotive, and aerospace uses, this four-conductor cable ensures durability through up to 1 million flex cycles. Its temperature range from -40°C to +80°C makes it versatile for static and dynamic applications. Purchase now for fast delivery and secure your connection in harsh conditions, ensuring safe, long-lasting operation.
Buy Alpha Wire 470041YYGE321 now and experience unmatched flexibility, durability, and resistance in demanding industrial applications.
Frequently Asked Questions
Where can I buy ALPHA WIRE 470041YYGE321?
You can click on the BUY or RFQ button to purchase 470041YYGE321 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 470041YYGE321?
You can download the 470041YYGE321 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 470041YYGE321?
ALPHA WIRE
