ALPHA WIRE 6344SL005 Shielded Multi-Conductor Cable
The 6344 SL005 is an 8-core shielded cable with a tinned copper conductor and semi-rigid PVC insulation. It features a slate-colored PVC jacket, offering excellent electromagnetic interference (EMI) protection via an aluminium/Mylar foil tape shield with foil facing out and a tinned copper braid shield with at least 65% coverage. Designed for reliable signal transmission, it withstands maximum pull tension of 51 pounds, with a ground capacitance of 65 pF/ft at 1 kHz and inductance of 0.18 µH/ft. Suitable for audio, communications, networking, sensors, security, automation, and portable electronics.
ALPHA WIRE 6344SL005 Shielded Multi-Conductor Cable Specifications:
- Conductor Material: Tinned copper
- Number of Cores: 8
- Insulation: Semi-rigid PVC, 0.010" wall
- Jacket Color: Slate
- Jacket Wall Thickness: 0.032"
- Shielding: Aluminium/Mylar foil tape, 25% overlap, foil facing out; Tinned copper braid, 65% coverage
- Maximum Pull Tension: 51 lbs
- Ground Capacitance: 65 pF/ft at 1 kHz
- Inductance: 0.18 µH/ft
- Voltage Rating: 300 V AC
- Capacitance: 36 pF/ft at 1 kHz
- Operating Temperature Range: -20°C to 80°C
- Bend Radius: 10 times cable diameter
- Length Options: 1000 ft, 500 ft, 100 ft
Buy the Buy AlphaWire Part Number 6344SL005 Online
Purchase the AlphaWire 6344SL005 shielded multi-conductor cable online today to benefit from high-quality EMI shielding, robust construction, and proven reliability. This 8-core cable features tinned copper conductors with semi-rigid PVC insulation and a slate-colored PVC jacket for durability. Its aluminium/Mylar foil shield with foil facing out, combined with a copper braid shield at 65% coverage, ensures excellent EMI protection for sensitive signals in audio, networking, and instrumentation. With a maximum pull tension of 51 lbs, it is ideal for demanding industrial and electronic environments ensuring longevity and performance.
Order your AlphaWire 6344SL005 shielded multi-conductor cable today and ensure reliable EMI protection for your sensitive electronic applications.
Frequently Asked Questions
Where can I buy ALPHA WIRE 6344SL005?
You can click on the BUY or RFQ button to purchase 6344SL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 6344SL005?
You can download the 6344SL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 6344SL005?
ALPHA WIRE
