ALPHA WIRE 652403SL005 Control Cable
This high-quality control cable is constructed with 24 AWG bare copper conductors insulated with 0.022" PVC wall, featuring a durable 0.035" PVC jacket in slate color. Designed for precise electronic control applications, it adheres to UL and CSA standards with a voltage rating of 600 V and temperature range from -40°C to 90°C. The cable configuration includes six twists per foot and water-resistant properties, making it suitable for industrial environments requiring reliable, flexible wiring solutions. It’s RoHS and REACH compliant, emphasizing environmental safety.
ALPHA WIRE 652403SL005 Control Cable Specifications:
- Conductor: 24 AWG bare copper
- Insulation: 0.022" PVC wall
- Jacket: 0.035" PVC, slate color, oil-resistant
- Twists per foot: 6.9
- Jacket thickness: 0.035"
- Voltage Rating: 600 V
- Temperature Range: -40°C to 90°C
- Bend Radius: 5X cable diameter
- Pull Tension: 10.6 lbs maximum
- Capacitance: 20.6 pF/ft @1 kHz
- Inductance: 0.24 μH/ft
- Conductor DCR: 23.8 Ω/1000 ft @20°C
- Length Options: 1000 ft, 500 ft, 100 ft
- Compliance: UL JAWMSTYLE 2587, CSA WII A/B, RoHS, REACH, CE
Buy the AlphaWire 652403 U– Reliable Control Cable for Industrial Applications
Purchase AlphaWire control cable now for reliable, flexible wiring in industrial environments. Made with 24 AWG bare copper conductors and PVC insulation, it offers excellent performance with 600V capacity and a temperature range from -40°C to 90°C. Fully compliant with RoHS, REACH, and UL standards, this cable ensures safety and durability. Available in various lengths, including 1000, 500, and 100 feet, it’s ideal for controlling machinery and electronic systems, providing secure connections with high flexibility and environmental resilience.
Get AlphaWire 652403 today—built for precision, environmental safety, and long-lasting durability.
Frequently Asked Questions
Where can I buy ALPHA WIRE 652403SL005?
You can click on the BUY or RFQ button to purchase 652403SL005 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 652403SL005?
You can download the 652403SL005 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 652403SL005?
ALPHA WIRE
