ALPHA WIRE 6624WH001 Cabled Electrical Wire
The Alpha Wire Part Number 6624WH001 features a 4-conductor cabled wire assembly with 24 AWG twisted conductors, protected by a 0.032-inch PVC jacket. Designed for electronic and electrical applications, it combines durability, flexibility, and compliance with international safety standards including UL VW-1 and CE. The cable withstands temperatures from -55°C to +105°C, with a voltage rating of 600 V. Its construction includes a clear Mylar core wrap with an 8 twists per foot twist rate, ensuring secure electrical performance in various environments. Perfect for control panels, instrumentation, and wiring harnesses demanding high reliability and safety.
ALPHA WIRE 6624WH001 Cabled Electrical Wire Specifications:
- Conductor: 24 AWG TC
- Insulation: 0.010" PVC, Irradiated
- Jacket: 0.032" PVC, White
- Colors: Red, Green, with clear Mylar tape core wrap
- Twists per foot: Minimum 8
- Outer diameter: 0.173" (max 0.184")
- Voltage Rating: 600 V
- Temperature Range: -55°C to +105°C
- Capacitance: 26 pF/ft @1 kHz
- Inductance: 0.19 μH/ft
- DCR: 26 Ω/1000ft @20°C
- UL Style 2576, VW-1 rated
- RoHS 2 and REACH compliant
- Certifications: UL, CE, RoHS, CSA
- Environmental compliance: EU Directive 2011/65/EU, China RoHS
Buy the Alpha Wire Series 2576 Cabled Wire Assembly: 6624WH001
Purchase the Alpha Wire Cabled Electrical Wire assembly featuring 24 AWG conductors, a durable PVC jacket, and compliance with UL, CE, RoHS standards. Designed for use in control panels, instrumentation, and wiring harnesses, this wire offers excellent flexibility, temperature resistance from -55°C to +105°C, and a voltage rating of 600 V. Its construction ensures secure electrical connections with twisted conductors, clear Mylar core wrap, and is suitable for environments requiring high safety standards and durability. Order now for reliable electrical wiring solutions.
Get Alpha Wire 6624WH001 today—built for electrical reliability and environmental compliance in demanding applications.
Frequently Asked Questions
Where can I buy ALPHA WIRE 6624WH001?
You can click on the BUY or RFQ button to purchase 6624WH001 from an authorized ALPHA WIRE distributor.
How do I troubleshoot issues or seek technical support for part 6624WH001?
You can download the 6624WH001 datasheet or visit the ALPHA WIRE website for support.
Who is the manufacturer of 6624WH001?
ALPHA WIRE
