ALPHA WIRE F105364BK005 Heat Shrink Tubing
The F1053/64 BK005 is a black heat shrink tubing made from irradiated PVC, designed for electrical insulation and protection. It features a 2:1 shrink ratio, minimum tensile strength of 2000 psi, and dielectric strength of at least 400 V/mil. The tubing recovers fully at 105°C and shrinks at a minimum temperature of 100°C. Operating reliably from -20°C to 105°C, it is suitable for safety and industrial uses, providing high durability, excellent insulation, and environmental resistance in demanding electrical and electronic applications.
ALPHA WIRE F105364BK005 Heat Shrink Tubing Specifications:
- Material: Irradiated PVC
- Color: Black
- Shrink Ratio: Approximately 2:1
- Minimum Recovered ID: 0.023 inches
- Maximum Recovered ID: 0.046 inches
- Minimum Wall Thickness: 0.020 inches
- Dielectric Strength: 400 V/mil, Min ASTM D876
- Tensile Strength: 2000 psi, Min ASTM D638
- Elongation: 300%, Min ASTM D638
- Temperature Range: -20°C to +105°C
- Full Recovery Temperature: 105°C
- Minimum Shrink Temperature: 100°C
- Shelf Life: 1 Year at 18-35°C
- Flammability: UL VW-1
- Compliance: RoHS, REACH, California Proposition 65
- Water Absorption: 1.00%, Max ASTM D570
- Volume Resistivity: 10^13 ohm-cm, Min ASTM D876
Buy the Buy AlphaWire Heat Shrink Tubing Part Number F105364BK005 Online
Purchase the AlphaWire F105364BK005 heat shrink tubing online for your electrical and industrial projects. Made from irradiated PVC, it offers a 2:1 shrink ratio, excellent dielectric properties, and a temperature range from -20°C to 105°C. Its full recovery at 105°C ensures a secure insulation even in demanding environments. With high tensile strength of up to 2000 psi and compliance with RoHS and REACH standards, this tubing guarantees safety, durability, and environmental friendliness. Order now to ensure reliable electrical protection with easy application and long-lasting performance.
Get AlphaWire F105364BK005 today—designed for electrical insulation with high durability and environmental resistance for industrial applications.
