ALPHA WIRE SW33NA005 Spiral Wrap Tubing
Spiral wrap tubing made from PTFE, providing excellent chemical resistance and high-temperature stability, with a natural/black color. Featuring a 0.500-inch outside diameter, 0.440-inch inside diameter, and 0.030-inch wall thickness, this flexible tubing is rated for temperatures ranging from -268°C to +260°C. Conforming to ASTM-D-3295-01 and UL VW-1 flammability standards, it is ideal for protecting cables in harsh environments. Suitable for various electrical and electronic applications, offering durability, flexibility, and compliance with EU RoHS2 and REACH regulations.
ALPHA WIRE SW33NA005 Spiral Wrap Tubing Specifications:
- Material: PTFE
- Color: Natural / Black
- Flammability: UL VW-1
- Outside Diameter: 0.500 inches +/- 0.015 inches
- Inside Diameter: 0.440 inches nominal
- Wall Thickness: 0.030 inches nominal
- Pitch: 0.500 inches nominal
- Pitch Direction: Right Hand
- Temperature Rating: -268°C to +260°C
- Applicable Specifications: ASTM-D-3295-01, UL VW-1
- Packaging: 100 FT or 25 FT lengths, maximum 3 lengths per package, 10 ft minimum length
- Environmental Compliance: RoHS2, REACH, no SVHC in excess of 0.1%
Buy the AlphaWire Series Spiral Wrap Tubing: SW33NA005
Order AlphaWire spiral wrap tubing online today to ensure reliable cable protection for harsh environments. This flexible PTFE tubing withstands extreme temperatures from -268°C to +260°C, offering excellent chemical resistance. Its UL VW-1 flammability rating guarantees safety, while compliance with RoHS2 and REACH regulations assures environmentally conscious manufacturing. Available in convenient 25 or 100-foot lengths, with a maximum of three pieces per package, it's an essential choice for electrical and electronic applications requiring high durability, flexibility, and regulatory compliance.
Buy AlphaWire SW33NA005 spiral wrap tubing now and experience unmatched durability, high-temperature resistance, and eco-friendly performance.
