AMERICAN ZETTLER AZ21501C12D Power Relay
This is a 12 V DC power relay with a single pole double throw contact configuration, supporting up to 20 amps and designed for PCB mounting. It features a single-side stable operation, Class B insulation, and unsealed contacts for easy access. The relay offers a maximum switching capacity of 20A at 250 VAC resistive load, with a resistant contact material of silver cadmium oxide. It has a relay operate time of max. 12 ms, release time of max. 5 ms, and a dielectric strength of 2500 Vrms contact to coil. Suitable for industrial automation and control systems, it complies with UL and VDE safety standards.
AMERICAN ZETTLER AZ21501C12D Power Relay Specifications:
- Coil Voltage: 12 VDC
- Coil Resistance: 17.5 Ω
- Max. Continuous Dissipation: 1.8 W at 40°C ambient
- Operate Time: Max. 12 ms
- Release Time: Max. 5 ms
- Dielectric Strength: 2500 Vrms contact to coil
- Insulation Resistance: >1000 MΩ at 500 VDC
- Contact Material: Silver cadmium oxide
- Contact Arrangement: SPDT (1 Form C)
- Contact Current: Up to 20 A
- Max. Switched Power: 250 VAC, 20 A
- Max. Switched Voltage: 250 VAC
- Weight: 25 grams
- Insulation Class: B
- Sealed: No
- Operating Temperature: -55°C to 100°C
- Storage Temperature: -55°C to 130°C
- Life Expectancy Mechanical: 10^7 operations, Electrical: 10^5 at 80 A 120 VAC resistive load
- Pad Layout: Suitable for PCB mounting with a 1/8 inch clearance, 0.045 inch creepage.
- Certifications: UL Listed, VDE Approved
Buy the Zettler AZ21501C12D – Reliable Power Relay for Industrial Applications
Buy the Zettler AZ21501C12D 12 V DC power relay online today and ensure your automation projects operate smoothly. Featuring 20A switching capability, SPDT contact configuration, and UL and VDE certifications, this relay provides reliable performance for industrial control, automation, and safety systems. Designed for PCB mounting with a compact form factor, it offers fast operation with a max. 12 ms operate time, high dielectric strength, and robust contact materials. Secure your order now for quality and durability.
Order your Zettler series AZ21501C12D 12 V DC power relay today and enhance your control systems with dependable switching capacity and quick response times.
