Amphenol Aerospace D3899924WD35SN MIL-DTL-38999 connector
The Amphenol MIL-DTL-38999 Series III jam nut receptacle features 37 contacts and is designed for high reliability in demanding environments. It offers a wide range of shell materials and finishes with salt spray resistance ranging from 48 to 2000 hours. The connector provides high-density contact arrangements within a compact circular shell, ensuring durable and secure connections. It is engineered to withstand extreme shock, vibration, and environmental exposure, making it suitable for military, aerospace, and industrial applications. Key features include moisture and corrosion resistance, exceptional EMI and RFI shielding, up to 500 mating cycles (with high durability versions supporting 1500 cycles), operation over a temperature range of -65°C to +200°C, minimum insulation resistance of 5000 MΩ at 500VDC, scoop-proof contact design, IP67 environmental protection, and a self-locking, triple-start threaded coupling system. The body is made of aluminum alloy with olive drab chromate over cadmium plating, while copper alloy crimp contacts are gold plated for reliable connections. The connector is also supported for inventory commonality, offering ease of replacement and compatibility across systems.
Amphenol Aerospace D3899924WD35SN MIL-DTL-38999 connector Specifications:
- Number of contacts: 37
- Shell material: Aluminum alloy with olive drab chromate over cadmium plating
- Contact plating: Gold-plated copper alloy
- Salt spray resistance: 48 to 2000 hours
- Temperature Range: -65°C to +200°C
- Insulation Resistance: Minimum 5000 MΩ at 500VDC
- Mating cycles: Up to 500, high durability versions up to 1500
- Environmental protection: IP67
- Cable retention: Self-locking, triple-start threaded coupling
- Design: Scoop-proof contact design
- Suitable for harsh environments: Shock, vibration, moisture, and corrosion resistant
Buy the Amphenol Series III MIL-DTL-38999 Jam Nut Receptacle: D3899924WD35SN
Enhance your system's reliability with the MIL-DTL-38999 Series III jam nut receptacle available online. Featuring 37 contacts, rugged aluminum construction with olive drab chromate finish, and IP67 environmental sealing, this connector delivers exceptional EMI and RFI shielding. Its self-locking triple-start threaded coupling ensures secure connections even in extreme conditions, making it ideal for aerospace, military, and industrial applications. Easy to replace, compatible across systems, and engineered for durability, buy this high-quality connector today for peak performance in demanding environments.
Buy Amphenol MIL-DTL-38999 Series III D3899924WD35SN connector now and experience unmatched reliability and rugged performance suitable for aerospace and military applications.
