AMPHENOL COMMUNICATIONS SOLUTIONS 68685310LF Board Connectors
The product is a high-quality board-to-board connector designed for industrial applications, featuring a low-profile, dual-beam contact structure that ensures reliable electrical performance and easy testing. Its robust construction includes UL94V-0 rated thermoplastic housing, gold or tin plating for corrosion resistance, and a broad operating temperature range of -65°C to +125°C. Suitable for both surface-mount and through-hole configurations, it offers durable mating cycles, high insulation resistance, and dielectric withstand voltage of 1000V RMS, making it ideal for complex electronic assemblies and automation systems.
AMPHENOL COMMUNICATIONS SOLUTIONS 68685310LF Board Connectors Specifications:
- Housing Material: Thermoplastic polyester, UL94V-0 rated, blue or grey depending on series
- Pin Material: Phosphor-bronze with gold or tin plating over nickel
- Current Rating: Up to 3A per contact
- Insulation Resistance: Minimum 50,000MQ or 1x10^10MQ
- Contact Resistance: Max 15MQ initial, 20MQ after environmental testing
- Dielectric Withstanding Voltage: 1000V RMS
- Operating Temperature Range: -65°C to +125°C
- Mating Cycles: 200 for vertical and horizontal series
- Insertion Force: Max 1.50 N (150gf) per gold contact
- Withdrawal Force: Min 0.30 N (30gf) per gold contact
- Insertion Depth: 3.6mm to 7.50mm depending on type
- Flammability Rating: UL94V-0
- Packaging: Plastic bags, tubes, tape-and-reel options
- Environmental Resistance: RoHS compliant, suitable for wave soldering and reflow processes
Buy the Brand 68685310LF – Reliable Board-to-Board Connectors for Industrial Applications
Enhance your electronic assemblies with our reliable board-to-board connectors, featuring dual-beam contacts and a low-profile design. These connectors are built to withstand harsh environments, with UL94V-0 rated thermoplastic housing, gold or tin plating for corrosion resistance, and high temperature tolerance of -65°C to +125°C. They offer up to 200 mating cycles, high insulation resistance, and dielectric withstand voltage of 1000V RMS, ensuring dependable connections for automation, industrial equipment, and complex electronic systems. Purchase online for quick delivery and superior quality.
Get Brand 68685310LF today—built for precision, durability, and reliable electrical connections in industrial assembly.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 68685310LF?
You can click on the BUY or RFQ button to purchase 68685310LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 68685310LF?
You can download the 68685310LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 68685310LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
