AMPHENOL COMMUNICATIONS SOLUTIONS 71918108LF Insulation Piercing Connector
The Quickie Connector System offers a reliable, insulation piercing connection for printed wiring board to flat cable or round conductor interfaces, ideal for low power applications. Made with full-hard phosphor bronze contacts and optional features such as latches, strain relief, and polarizing keys, it ensures secure, durable connections. The system is designed for easy mating and unmating by hand, with optional locking mechanisms. Suitable for environments requiring high humidity, vibration, and thermal shock resistance, it complies with military and industry standards, ensuring consistent performance across demanding conditions.
AMPHENOL COMMUNICATIONS SOLUTIONS 71918108LF Insulation Piercing Connector Specifications:
- Material: Full-hard phosphor bronze contacts, polyester plastic parts with torch-rated flame retardant 94V-0 coating, optional nylon keys
- Finish: Gold (MIL-45204B GXT) or tin-lead plating on contacts; nickel plating for connectors
- Contact Resistance: ≤10 milliohms, withstands 100 mating cycles with no more than 15 milliohms
- Current Rating: 1.0 ampere DC per contact
- Insulation Resistance: ≥20,000 megohms after humidity exposure, ≥50,000 megohms when unmated
- Dielectric Withstanding Voltage: ≥1,000 volts RMS at sea level
- Mechanical: Cable retention force ≥10 pounds per inch; total mating force within specified limits; contact to housing retention ≥1 lb
- Environmental: Resistance to humidity (96 hours at 90% RH @ 40°C), thermal shock (-65°C to +105°C), high temperature life (85°C for 250 hours), vibration (up to 15G), shock (100G), H2S and salt spray resistance
Buy the Quickie Connector System – Reliable PCB-to-Cable Interconnection for Industrial Applications
Purchase the Quickie Connector System online today to ensure secure, reliable connections for PCB and cable interfaces. Designed to withstand harsh conditions including humidity, vibration, and extreme temperatures, this connector offers excellent durability and ease of use. With optional locking, strain relief, and polarizing features, it simplifies installation and maintenance in industrial applications. Efficient and maintenance-free, it guarantees long-term performance, making it the ideal choice for engineers and technicians needing dependable electrical interconnections in low power systems.
Buy Quickie Connector System now and experience unmatched reliability, durability, and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 71918108LF?
You can click on the BUY or RFQ button to purchase 71918108LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 71918108LF?
You can download the 71918108LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 71918108LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
