AMPHENOL COMMUNICATIONS SOLUTIONS 76384403LF Wire-to-board connector
This wire-to-board connector system offers high reliability with dual-metal PV receptacle contacts that maintain contact pressure through 1000 mating cycles. Compatible with industry-standard 0.025 inch posts, it features a beryllium copper spring for high normal force and a brass contact body for gas-tight crimps. Its design includes shrouded headers and MINI-LATCH housings for secure mating, suitable for industrial, medical, automotive, and communication applications. The system is RoHS compliant, withstands voltage up to 1000V RMS, and supports wire diameters up to 1.52mm, ensuring robust electrical and mechanical performance.
AMPHENOL COMMUNICATIONS SOLUTIONS 76384403LF Wire-to-board connector Specifications:
- Contact Material: Brass body and beryllium copper spring
- Contact Plating: Gold or lead-free pure tin over nickel
- Housing Material: Modified polyphenylene oxide UL94V-0 (Mini-LATCH), Glass filled nylon UL94V-0 (Headers)
- Current Rating: 3.0A with 32 AWG wire; de-rating applies for larger wires
- Withstand Voltage: 1000V RMS
- Insulation Resistance: >10000MQ (wire connector), >5000MQ (header)
- Contact Resistance: <2mQ
- Durability: 1000 mating cycles
- Temperature Range: -40°C to +105°C
Buy the Buy FCI Wire-to-Board Connector Part Number 76384403LF Online
Discover the high-performance FCI wire-to-board connector with dual-metal contacts, shrouded headers, and MINI-LATCH housings that ensure secure connections. Perfect for industrial, medical, automotive, and communication equipment, this connector provides reliable electrical connections, high durability, and RoHS compliance. Supports wire sizes up to 1.52mm, withstands voltages up to 1000V RMS, and offers easy tooling for crimping and termination. Ensure your application benefits from robust design, long cycle life, and optimal electrical performance by purchasing online today.
Buy FCI 76384403LF wire-to-board connector now and experience unmatched reliability and performance for industrial, medical, and automotive electronics.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 76384403LF?
You can click on the BUY or RFQ button to purchase 76384403LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 76384403LF?
You can download the 76384403LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 76384403LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
