AMPHENOL COMMUNICATIONS SOLUTIONS L177SDA15SOL2 PCB Connector
The Amphenol SD series features precision-formed contacts and insulators with closed entry contact cavities, providing high reliability and quality. Suitable for PCB connections in industrial, telecom, and standard industries, this economical connector ensures secure electrical performance with plated contacts and robust materials. The series supports both standard and high-density configurations, offering various pin counts, and complies with MIL C24308 and NFC 93425-HES standards, making it ideal for reliable, high-performance electronic connections in demanding environments.
AMPHENOL COMMUNICATIONS SOLUTIONS L177SDA15SOL2 PCB Connector Specifications:
- Materials: Steel shell, thermoplastic insulator UL 94V-0, brass and phosphor bronze contacts with gold and nickel plating
- Electrical: 5A (standard density), 3A (high density), 250V AC rms voltage, 1000V AC rms withstand voltage, 1000 MO insolation resistance
- Contact Resistance: ≤20mΩ, Operating Temperature: -55°C to +125°C, Salt spray resistance 24 hours
- Mechanical: Single contact insertion force range: SD 0.06kg to 12.51kg, HD 0.02kg to 15.82kg; Mating/unmating force varies with contact count
- Physical Dimensions: Overall length approx. 12.55mm to 69.32mm depending on model, various pin counts from 9 to 78, with specific dimension details for mounting and contact spacing
- Standards: MIL C24308, NFC 93425-HES, RoHS compliant
Buy the Buy Amphenol SD Series Connector Part Number L177SDA15SOL2 Online
Purchase the Amphenol SD series PCB connector L177SDA15SOL2 online and enjoy the benefits of high-quality, precision-formed contacts suitable for industrial, telecom, and standard applications. Designed for both standard and high-density configurations, this connector offers excellent electrical performance, advanced materials, and robust construction ensuring secure connections and durability under demanding conditions. Shop now to enhance your electronic systems with reliable, RoHS-compliant connectors that meet stringent industry standards and ensure long-lasting, high-performance connections.
Buy Amphenol SD series connector L177SDA15SOL2 now and experience unmatched reliability and high-performance PCB connections for industrial and telecom uses.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS L177SDA15SOL2?
You can click on the BUY or RFQ button to purchase L177SDA15SOL2 from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part L177SDA15SOL2?
You can download the L177SDA15SOL2 datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of L177SDA15SOL2?
AMPHENOL COMMUNICATIONS SOLUTIONS
