AMPHENOL COMMUNICATIONS SOLUTIONS L17H2220131 D-Sub Connector
This D-sub connector features a 9-position female shell with bright tin finish and gold flash contacts, designed for reliable electrical connections in industrial and electronic applications. Made with high-quality materials including copper alloy contacts, PBT body rated UL 94V-0, and zinc alloy brackets, it supports a voltage rating of 250 V RMS and a current of 3 amps. With a withstand voltage exceeding 1000 V RMS and insulation resistance over 1000 M Ohms, this connector ensures durability and safety for various electrical systems and device connections.
AMPHENOL COMMUNICATIONS SOLUTIONS L17H2220131 D-Sub Connector Specifications:
- Shell Material: SPCC with 100u” Tin over 50u” Nickel
- Body Material: PBT, UL 94V-0, Black color
- Contacts: Copper alloy with gold flash on mating area and tin over nickel on solder area
- Boardlock: Copper alloy, Tin plated
- Bracket: Zinc alloy, Nickel plated
- Screwlock: Copper alloy, Nickel plated
- Voltage Rating: 250 V RMS
- Current Rating: 3 Amps
- Withstanding Voltage: >1000 V RMS
- Insulation Resistance: >1000 M Ohms
- Contact Resistance: 25 mOhms max
- Connector Type: 9 Pos. Female
- Finish: Bright Tin (shell), Gold flash (contacts)
- Mounting Options: Flange, boardlock
- Spacing Between Ports: 19.05mm or 31.60mm
- RoHS Compliance: Yes
Buy the Amphenol L17H2220131 – Reliable D-Sub Connector for Industrial Applications
Order the durable and reliable D-Sub connector online now. Featuring a 9-position female shell with tin and gold finishes, rated for 250 V RMS and 3 amps, it ensures secure electrical connections. Crafted from high-quality materials like copper alloy contacts, UL-rated PBT body, zinc alloy brackets, and snug screwlock and boardlock options, this connector offers excellent insulation resistance over 1000 M Ohms and withstands voltages above 1000 V RMS. Perfect for industrial, electronic, and communication equipment, buy now for quality and performance.
Get Amphenol L17H2220131 today—built for precision and long-lasting durability in electronic connections.
