AMPHENOL COMMUNICATIONS SOLUTIONS L777RRB25P D-Sub Connector Housing
The L777-RR-B25P is a 25-position D-sub connector housing with a tin-plated finish. It features a standard rivet Ø0.12mm rear mounting and is made from black glass-filled thermoplastic with UL94V-0 fire resistance rating. Compatible with RR series D-sub contacts, it offers a maximum withstand voltage of 1000VAC/rms at 50Hz for 1 minute, and an insulation resistance of 5000 megaohms. The operating temperature range spans from -55°C to 105°C. Suitable for applications in defense, military, aerospace, communications, networking, and industrial sectors.
AMPHENOL COMMUNICATIONS SOLUTIONS L777RRB25P D-Sub Connector Housing Specifications:
- Shell Material: Steel yellow chromated over zinc or tinned steel
- Insulator Material: Black glass-filled thermoplastic, UL 94V-0
- Rear Insert: Brass, 118u" up to 197", tinned over nickel 78u" up to 118u"
- Contacts: Crimp side, gold or nickel plated, under plating gold 20u" or 30u"
- Current Rating: 5A
- Voltage Rating: 500V AC/rms, Withstanding Voltage RR: 1000V AC/rms for 1 minute
- Insulation Resistance: RR: 5000MQ, HR: 1000MQ
- Contact Resistance: Max 10mΩ
- Wire Size: 20-28 AWG
- Operating Temperature: -55°C to +105°C
- Mounting: Rear rivet Ø0.12mm, compatible with standard rear insert
- Compatibility: Suitable for RR series D-sub contacts
- Dimensions: Standard shell sizes, specific dimensions vary with model
- Certifications: UL Listed, compliant with MIL C24308
Buy the Amphenol Connectors 25-Position D-Sub Housing – Reliable Interconnect for Industrial Applications
Order the Amphenol D-Sub connector housing online today to ensure robust, reliable connections for your industrial, aerospace, and communication projects. Designed with a durable thermoplastic shell and gold or nickel-plated contacts, this connector offers excellent resistance to extreme temperatures and electrical stress. Compatible with RR series contacts, it provides a maximum withstand voltage of 1000VAC for 1 minute and features UL94V-0 fire resistance. Improve your assembly efficiency with fast, secure mounting and consistent performance in critical applications.
Get Amphenol L777-RR-B25P today—built for precision, durability, and high-performance connectivity in demanding industrial environments.
