Amphenol PCD, Inc. JE19 Ethernet Connector
This field-installable Ethernet and telecom connector offers a weather-resistant, secure connection with a gasket, designed for reliable outdoor and harsh environment applications such as telecommunications, networking, and industrial systems. It features IP67 sealing, shock and vibration resistance, and EMI protection, making it ideal for demanding environments. The connector is easy to install without tools, ensuring quick setup and durability with salt spray resistance, temperature range from -55°C to +85°C, and high mechanical robustness for data transmission at 400 Mbits/sec over 4.5 meters. Suitable for military, marine, and industrial use.
Amphenol PCD, Inc. JE19 Ethernet Connector Specifications:
- Sealing: IP67 (Temporary immersion - 1M up to 30 minutes)
- Data Rate: 400 Mbits/sec over 4.5 meters
- Temperature Range: -55°C to +85°C
- Vibration: 10–500 Hz, 10 g, 3 axes, no discontinuity > 1 microsecond
- Shock Resistance: Drop from 40 cm (15.75 in) with 250 g weight
- Salt Spray Resistance: 48 hr with Nickel plating, 500 hr with Olive Drab Cadmium
- Fire Retardant / Low Smoke: UL94 VO, NF F 16 101 & 102
- Housing Material: Metal with conductively plated shells (Ni, Cd)
- Mating Cycles: 500 to 1500 times
- Mechanical: Tri-start thread coupling MIL-DTL-38999 series III with anti-decoupling device
- Connector Compatibility: IEEE 1394, telecom, Ethernet applications
- Installation: Tool-free, quick assembly with gasket and sealing features
Buy the Amphenol Series IEEE 1394 Ethernet Connector: FWF TV
Order the Amphenol FWF TV Ethernet connector online today and ensure your networking or industrial systems operate reliably in outdoor and extreme conditions. Designed with IP67 sealing, shock, vibration, and EMI resistance, this connector guarantees durable performance for demanding applications. Suitable for telecommunications, military, and marine environments, it features easy tool-free installation, salt spray resistance, and a temperature range from -55°C to +85°C. Secure your connection with a trusted solution that combines durability, flexibility, and high data integrity.
Buy Amphenol FWF TV IEEE 1394 Ethernet connector now and experience unmatched weather resistance, durability, and reliable data transmission in harsh environments.
Frequently Asked Questions
Where can I buy Amphenol PCD, Inc. JE19?
You can click on the BUY or RFQ button to purchase JE19 from an authorized Amphenol PCD, Inc. distributor.
How do I troubleshoot issues or seek technical support for part JE19?
You can download the JE19 datasheet or visit the Amphenol PCD, Inc. website for support.
Who is the manufacturer of JE19?
Amphenol PCD, Inc.
