AMPHENOL RF 095850220036 Coaxial Connector
The product is a waterproof, IP67 rated TNC or RP-TNC connector designed for reliable and secure connections in outdoor, industrial, wireless, military, and broadband applications. Featuring a threaded coupling mechanism, these connectors provide excellent durability, tamper resistance, and strong environmental sealing against moisture and external tampering. They are available in various configurations including straight, right-angle, front, rear mount, free-hanging, and PCB mount versions, suitable for a range of coaxial cable types like LMR and RG series. These connectors ensure stable electrical performance up to 11 GHz and are compliant with RoHS standards, making them ideal for high-performance, rugged systems.
AMPHENOL RF 095850220036 Coaxial Connector Specifications:
- Impedance: 50 ohms
- Frequency Range: DC - 11 GHz
- Return Loss: 3 (-18 dB) Max
- Dielectric Withstanding Voltage: 1500 VRMS Max
- Insulation Resistance: 5000 MO Min
- Contact Resistance: Center Contact 1.5 mQ Max, Outer Contact 0.2 mQ Max
- Coupling Style: Threaded
- Mating Cycles: 500 Min
- Temperature Range: -65°C to +165°C
- Material - Body & Outer Contacts: Brass, Brass Beryllium Copper
- Female Contact: Beryllium Copper, Brass
- Crimp Ferrule: Copper
- Insulator: PTFE
- Gasket: Silicone
- RoHS Compliance: Exemption 6C
Buy the Amphenol Series Waterproof TNC: 095850220036
Discover the high-performance waterproof TNC connector designed for outdoor and industrial applications. Featuring IP67 sealing, threaded coupling, and exceptional durability, this connector ensures reliable connections in harsh environments. Suitable for antennas, wireless, military, and broadband systems, it maintains excellent electrical performance up to 11 GHz. Easy to install with various configurations including straight, right-angle, front, rear mount, and PCB mount options. Perfect for applications demanding secure, weatherproof, and tamper-resistant coaxial connections. Order online now for fast delivery.
Get Amphenol waterproof TNC connector today—built for rugged outdoor use and long-lasting durability.
Frequently Asked Questions
Where can I buy AMPHENOL RF 095850220036?
You can click on the BUY or RFQ button to purchase 095850220036 from an authorized AMPHENOL RF distributor.
How do I troubleshoot issues or seek technical support for part 095850220036?
You can download the 095850220036 datasheet or visit the AMPHENOL RF website for support.
Who is the manufacturer of 095850220036?
AMPHENOL RF
