AMPHENOL RF 095850264100 Rugged Waterproof RF Connector
This waterproof and tamper-resistant TNC and RP-TNC connector series offers 50 ohm impedance with IP67 sealing, threaded coupling, and durable brass and copper construction. Suitable for antennas, industrial, wireless, military, and broadband applications, these connectors feature various configurations including straight, right-angle, bulkhead, and PCB mounts. They provide excellent electrical performance with a frequency range DC to 11 GHz, low VSWR, and high dielectric withstand voltage. Designed for reliable, secure connections in harsh environments, they are ideal for demanding communication systems requiring rugged and waterproof interfaces.
AMPHENOL RF 095850264100 Rugged Waterproof RF Connector Specifications:
- Impedance: 50 ohms
- Frequency Range: DC - 11 GHz
- Return Loss: 3 (-18 dB) Max.
- Dielectric Withstanding Voltage: 1500 VRMS Max.
- Insulation Resistance: 5000 MΩ Min.
- Contact Resistance: Center Contact 1.5 mΩ Max., Outer Contact 0.2 mΩ Max.
- Coupling Style: Threaded
- Mating Cycles: 500 Min.
- Temperature Range: -65°C to +165°C
- Materials: Brass, Brass Beryllium Copper, Copper, PTFE Insulator, Silicone Gasket
- RoHS: Compliant with Exemption 6C
Buy the Amphenol Series IP67 Waterproof TNC Connector: 095850264
Purchase the Amphenol waterproof RF connector online today for secure, stable connections in outdoor and industrial environments. Designed for durability, these connectors feature IP67 sealing, threaded coupling, and high-frequency performance up to 11 GHz. Ideal for antennas, military use, broadband, and wireless systems, they support multiple configurations including straight, right-angle, bulkhead, and PCB mounts. With robust materials like brass and copper, these connectors ensure long-term performance and resistance to elements. Order now to enhance the reliability of your communication systems and enjoy fast delivery and excellent customer support.
Get Amphenol waterproof TNC connector today—built for reliability in harsh environments and long-lasting durability.
Frequently Asked Questions
Where can I buy AMPHENOL RF 095850264100?
You can click on the BUY or RFQ button to purchase 095850264100 from an authorized AMPHENOL RF distributor.
How do I troubleshoot issues or seek technical support for part 095850264100?
You can download the 095850264100 datasheet or visit the AMPHENOL RF website for support.
Who is the manufacturer of 095850264100?
AMPHENOL RF
