AMPHENOL RF 172148 Bulkhead Receptacle
This high-performance bulkhead mount solder receptacle features nickel-plated body and Teflon insulation, designed for reliable RF connections up to 11 GHz. Its compact design allows easy panel mounting with a 50 ohm impedance, suitable for demanding telecommunications and microwave applications. The connector ensures low voltage rating of 1500 Volts peak and dielectric withstand voltage of 2500 Volts rms, with gold or silver plating options for contacts. Crafted from durable materials, it provides excellent electrical stability and mechanical ruggedness for industrial and aerospace systems.
AMPHENOL RF 172148 Bulkhead Receptacle Specifications:
- Impedance: 50 Ω
- Frequency Range: 0-11 GHz
- Voltage Rating: 1500 Volts peak
- Dielectric Withstanding Voltage: 2500 Volts rms
- Contact Resistance: Center contact 1.0 milliohm, Outer contact 0.2 milliohm
- Insulation Resistance: 5000 megohms (min)
- Material: Nickel-plated body, Teflon insulator
- Finish: Nickel or Silver platted contacts
- Connector Mounting: Front mount
- Dimensions: Compatible with standard panel thickness and mounting hole specifications
- Certifications: Design compliant with RF standards for industrial and aerospace use
Buy the Connex Series N Bulkhead Mount Solder Receptacle: 172148
Purchase the high-performance Connex series bulkhead mount solder receptacle online. Crafted with nickel plating and Teflon insulation, it provides reliable RF performance up to 11 GHz. Perfect for demanding telecom, aerospace, and industrial systems, offering low contact resistance, high dielectric voltage withstand, and excellent mechanical durability. This connector ensures stable electrical connection and easy panel mounting, making it an essential component for engineers seeking quality and precision in RF applications. Buy now for fast shipping and expert support.
Get Connex Series N bulkhead mount solder receptacle 172148 today—designed for high-frequency RF applications with durable nickel plating and Teflon insulation.
Frequently Asked Questions
Where can I buy AMPHENOL RF 172148?
You can click on the BUY or RFQ button to purchase 172148 from an authorized AMPHENOL RF distributor.
How do I troubleshoot issues or seek technical support for part 172148?
You can download the 172148 datasheet or visit the AMPHENOL RF website for support.
Who is the manufacturer of 172148?
AMPHENOL RF
