Amphenol Sine Systems AT0412PAKIT01 12 Position Receptacle Kit
The Amphenol Sine Systems AT04-12PA-KIT01 is a 12-position circular connector kit designed for demanding industrial applications. The kit includes a receptacle, contacts, and a P-Wedgelock. The housing is constructed from durable thermoplastic, while the seals are made of silicone rubber for reliable environmental protection. The nickel-plated copper alloy contacts ensure excellent conductivity and corrosion resistance. This connector is ideal for applications requiring a robust, sealed connection, such as automotive, industrial automation, and power distribution systems. It is RoHS compliant and offers a wide operating temperature range and high dielectric withstanding voltage.
Amphenol Sine Systems AT0412PAKIT01 12 Position Receptacle Kit Specifications:
- Current Rating: 13 Amps
- Operating Temperature: -55°C to +125°C
- Dielectric Withstanding Voltage: Less than 2 milliamp current leakage @ 1500 Volts AC
- Insulation Resistance: 1000 Megohms Min @ 25°C
- Contact Millivolt Drop: 60 Millivolt Drop @ 13 Amp Test Current
- Moisture Resistance: IP67 (mated condition)
- Connector Mating Cycle Durability: 100 Cycles
- Material - Housing: Thermoplastic, Grey
- Material - Wedgelock: Thermoplastic, Green
- Material - Seals: Silicone Rubber
- Material - Contacts: Copper Alloy, Nickel Plated
- Wire Range: 16 - 20 AWG
- Contact Size: 16
- Contact Min Insulation O.D.: 2.24 mm
- Contact Max Insulation O.D.: 3.68 mm
