Anderson Power Products 1307BK Electrical Connector
The Anderson SB-50 connectors offer a cost-effective, reliable, and flexible solution for electrical power distribution, battery connections, and industrial applications. Featuring a one-piece plastic housing with stainless steel springs, these connectors support wire sizes from #16 to #6 and provide UL-rated currents up to 120 amps. They are suitable for both wire and PCB connections, with optional chemical-resistant housings and silver-plated contacts. Designed for durability, safety, and ease of mating, SB-50 connectors are ideal for reliable, high-current connections in demanding environments.
Anderson Power Products 1307BK Electrical Connector Specifications:
- Current Rating: Up to 120 amps
- Voltage Rating: 600V AC/DC
- Wire Size Range: #16 to #6 AWG (1.3 mm to 13.3 mm) includes wire and PCB contacts
- Temperature Range: -40°C to +105°C
- Material: Plastic housing with stainless steel springs, copper contacts with silver or tin plating
- Mechanical Mating Cycles: 10,000 for wire contacts, 1,500 for PCB contacts
- Dielectric Withstanding Voltage: 2,200V AC
- Environmental Resistance: IP64, chemical resistant options available
- Dimensions: Standard housing supports wire sizes from #16 to #6 AWG, contact dimensions vary by contact type
- Accessories include handles, dust covers, environmental boots, cable clamps, and guide housings
Buy the Anderson Series SB-50 Electrical Connector: 1307BK
Secure your electrical connections efficiently with Anderson SB-50 connectors. Supporting up to 120 amps, these connectors are designed for durability, safety, and easy installation. Ideal for power distribution, battery connections, and industrial use, they feature robust plastic housings with stainless steel springs and silver or tin-plated copper contacts. Available in multiple housing options, including chemical-resistant versions. Purchase online today to ensure reliable, high-current connections with ease and confidence, backed by trusted quality and versatile features.
Buy Anderson SB-50 connector 1307BK now and experience unmatched reliability and high-current performance for industrial and battery applications.
Frequently Asked Questions
Where can I buy Anderson Power Products 1307BK?
You can click on the BUY or RFQ button to purchase 1307BK from an authorized Anderson Power Products distributor.
How do I troubleshoot issues or seek technical support for part 1307BK?
You can download the 1307BK datasheet or visit the Anderson Power Products website for support.
Who is the manufacturer of 1307BK?
Anderson Power Products
