Anderson Power Products 1463G1 Powerpole Connector
The Anderson Power Products Powerpole® connector provides reliable, cost-effective, and flexible connectivity solutions for wire-to-wire, wire-to-board, and busbar connections. The PP75 housings accommodate wire sizes from #16 AWG to #6 AWG, offering power capabilities up to 120 amps per pole. The housings are available in standard, chemical-resistant, and locking variants, with optional accessories like mounting wings and strain relief grommets for versatile installation. Constructed from durable, UL 94V-0 rated plastics, these connectors support up to 10,000 mating cycles, making them ideal for industrial and electrical applications. Temperature range from -40°C to +105°C ensures performance under harsh environments.
Anderson Power Products 1463G1 Powerpole Connector Specifications:
- Current Rating: up to 120 Amps per pole
- Wire Size Range: #16 AWG (1.3 mm) to #6 AWG (13.3 mm)
- Voltage Rating: 600V AC/DC
- Operating Temperature: -40°C to +105°C
- Materials: Polycarbonate, PBT/PC blend (chemical resistant), stainless steel (spring)
- Housing Flammability: UL 94V-0
- Mating Cycles: 10,000 for wire contacts, 1,500 for PCB contacts
- Dielectric Voltage: 2,200V AC
- Pollution Degree: 2
- Ingress Protection: IP10 for wire contacts
- Grommets and mounting accessories available for strain relief and mounting
- Locking and stacking features available for secure connections
- Compatible with a range of accessories for mounting and strain relief
- Assembly Methods: Crimp, wave solder, solder dip
- Housing and contact dimensions vary by configuration but designed for easy insertion/removal and durability
- Supports environmental sealing when combined with specific accessories, suitable for industrial environments
Buy the Anderson Series PP75 Powerpole Connector: 1463G1
Purchase the Anderson Powerpole PP75 connector series online today and enjoy reliable, flexible connectivity solutions for your electrical projects. These housings support wire sizes from #16 to #6 AWG, providing up to 120 amps per pole. Featuring durable materials, various locking and stacking options, and accessories like strain relief grommets and mounting wings, the PP75 series is ideal for industrial, commercial, and custom electrical applications. Order now for fast delivery and trusted performance in harsh environments.
Order your Anderson Series PP75 Powerpole Connector today and give your projects the dependable, versatile connectivity they need for reliable electrical systems.
Frequently Asked Questions
Where can I buy Anderson Power Products 1463G1?
You can click on the BUY or RFQ button to purchase 1463G1 from an authorized Anderson Power Products distributor.
How do I troubleshoot issues or seek technical support for part 1463G1?
You can download the 1463G1 datasheet or visit the Anderson Power Products website for support.
Who is the manufacturer of 1463G1?
Anderson Power Products
