Anderson Power Products 36034P1 High-Current Power Connector
The SB 120 Connectors are high-current, reliable connectors rated up to 240 amps, designed for industrial applications. They feature color-coded, mechanically keyed housings for circuit identification, and employ silver-plated wire contacts offering superior electrical performance and durability for up to 10,000 mating cycles. The chemical-resistant housings extend temperature ranges down to -40°C and are suitable for harsh environments. These modular connectors support wire sizes from 10 to 1 AWG, including busbar options, and accommodate panel mounting with integral grooves. They are ideal for power distribution, automation, and electrical systems requiring robust, high-current connections with environmental sealing and flexibility.
Anderson Power Products 36034P1 High-Current Power Connector Specifications:
- Current Rating: Up to 240A
- Voltage Rating: 600V AC/DC
- Wire Size Range: 10 to 1 AWG (5.3 to 42.4 mm?)
- Contact Material: Copper Alloy with Silver Plating
- Housing Material: Polycarbonate or Chemical Resistant PBT/PC blend
- Operating Temperature: -40°C to 105°C
- Maximum Insulation Diameter: 0.600 inches (15.24 mm)
- Mating Cycles: 10,000
- Dielectric Withstanding Voltage: 2,200V AC
- Impact Resistance: IEC 60512-5 testing, 8 impacts at 29.5 inches
- Environmental Sealing: IP64 with boots
- Certifications: UL 1977, CSA
- Structural Features: Mechanical keys, panel mounting grooves
- Optional Accessories: Mounting clamps, dust covers, environmental boots
- Busbar Contacts: Use with lock nuts, rated for quick disconnects, lock nuts ordered separately
- Electrical Performance: Low contact resistance, withstands 10,000 mating cycles
Buy the Anderson SB 120 – Reliable Power Connectors for Industrial Applications
Order Anderson SB 120 high-current connectors online today and enjoy reliable, durable power connections suited for demanding industrial environments. Featuring silver-plated contacts, chemical-resistant housings, and a modular, color-coded design, these connectors support wire sizes up to 1 AWG and currents up to 240 amps. They are ideal for power distribution, automation, and electrical systems requiring rugged, environmentally sealed connections. Easy to mount with panel grooves, they ensure secure, high-performance connectivity with long-term durability in harsh conditions.
Buy Anderson SB 120 connectors now and experience unmatched reliability, high current capacity, and environmental protection for industrial power systems.
