Apem PBAR9AF6000N0S Piezo Switch
The PBAR9A Piezo switch features a non-illuminated, flat operator with a height of 3 mm and a chamfer design, made from durable anodized aluminum. It is rated for 24VAC/DC with a maximum current of 1A, and offers a long operational life of 50 million cycles. Suitable for panel mounting with standard hardware, the switch is designed for applications requiring reliable, sealed electronic control with easy maintenance. It includes multi-wire leads, sealed terminals, and is compatible with hazardous environments, providing robust performance and environmental resistance.
Apem PBAR9AF6000N0S Piezo Switch Specifications:
- Bushing Diameter: 22mm
- Operator Height: 3mm
- Material: Anodized aluminum (Natural, Blue, Black, Green, Gold, Red)
- Terminals: Multi-wire leads, 0.22 mm², length 300mm
- Rated Voltage: 24VAC/DC
- Max. Current: 1A (standard), 200mA (alternative)
- Switch Resistance ON: 10Ω max
- Switch Resistance OFF: 5MQ min
- Sealing: IP66 per IEC 60529
- Operating Temperature: -40°C to +55°C
- Life Expectancy: 50 million cycles
- Operating Force: 2 to 6N
- Torque: 2.5 Nm max
- Hardware: Hex nut 10-855-0, O-ring, ground washer US736
- Environmental Resistance: Suitable for use in explosive atmospheres, compliant with ATEX standards
- LED Compatibility: Non-illuminated version, designed for rugged industrial environments
Buy the Buy APEM Piezo Switch Part Number PBAR9AF6000N0S Online
Purchase the APEM PBAR9AF6000N0S piezo switch online today and enjoy fast delivery, easy installation, and a long operational life. This high-quality, sealed switch is designed for industrial control panels, offering durability and resistance to harsh environments. Its robust construction from anodized aluminum ensures reliable operation over millions of cycles, making it ideal for safety-critical applications in explosive atmospheres. Order now to ensure your control equipment maintains high performance with this proven industrial component.
Buy APEM PBAR9AF6000N0S now and experience unmatched reliability and performance in hazardous environmental conditions.
