Apem Q12P1BXXB110E Panel Mount LED Indicator
The Q12P1BXXB110E is a blue panel-mount LED indicator with a prominent black chrome bezel, available with solder lug or faston terminals for reliable mounting. It operates at 110VAC with a bright, fixed illumination ideal for industrial signaling. Featuring IP67 sealing to resist dust and water ingress, it offers long life expectancy of 100,000 hours and a viewing angle of 60°. Suitable for panel thickness up to 7mm, it includes fixing hardware for secure installation and maintains consistent brightness and performance in harsh environments.
Apem Q12P1BXXB110E Panel Mount LED Indicator Specifications:
- Operating Voltage: 110VAC with a range of 99 to 121VAC
- Current: 3mA at 110VAC
- LED Color: Blue with high brightness (super bright) options available
- Forward Voltage: 3.6V typical at specified current
- Viewing Angle: 60°
- Luminous Intensity: 1,500 med
- Life Expectancy: 100,000 hours
- Sealing: IP67 (waterproof and dustproof)
- Panel Thickness Compatibility: up to 7mm
- Terminals: Solder lug or faston (gold or silver)
- Max Reverse Voltage: 5V
- Temperature Range: -40°C to +85°C
- Fixing: Includes fixing nut and spring washer for secure installation
Buy the Q-SERIES Panel Mount LED Indicator: 110VAC Blue LED Backlit
Enhance your industrial control panels with the Q-SERIES Panel Mount LED Indicator featuring a bright blue LED, IP67 sealing, and robust construction. Suitable for 110VAC operation, it guarantees long life and clear visibility, even in harsh environments. Easy to install with included fixing hardware, this indicator promises reliable performance and durable operation. Order now to ensure your signaling systems operate with high visibility and durability, backed by quality and precision, for industrial, automation, or machinery applications.
Buy Q-SERIES Panel Mount LED Indicator with 110VAC blue LED now and experience reliable, durable industrial signaling performance.
