Apem Q14P1CXXW12E LED Indicator
The 14mm prominent, waterproof LED indicator features a bright white bezel with IP67 sealing for outdoor and harsh environment applications. It offers a choice of colors including red, green, yellow, blue, and white, with super bright LED options. Suitable for 12VDC and 12VAC/DC systems, this indicator supports flush or prominent bezel styles with solder lug or wire terminations. Its long life expectancy of 100,000 hours, operating temperature range of -40°C to +85°C, and operating voltages from 1.8V to 253V make it reliable and versatile for industrial, control panels, and instrumentation projects.
Apem Q14P1CXXW12E LED Indicator Specifications:
- Bezel Finish: Bright chrome, black chrome, satin grey, or white
- Lens: 10mm diffused epoxy or water clear super bright LEDs
- Size: 14mm panel mounting with max panel thickness 11mm
- Operating Voltage: 1.8V to 253VDC/VAC depending on model
- Current: 20mA typical for most voltages, 6mA for 230VAC
- Luminous Intensity: Up to 7,500 mcd (Red), 4,100 mcd (Green), 2,500 mcd (Yellow), etc.
- Viewing Angle: 100°
- Life Expectancy: 100,000 hours
- Operating Temp Range: -40°C to +85°C
- Ingress Protection: IP67
- Connection: Solder lug or 200mm wire terminations
- Max Reverse Voltage: 5V
- Installation: Suitable for control panels, industrial equipment, outdoor use
Buy the Buy Apem Q-Series 14mm LED Indicator Part Number Q14P1CXXW12E Online
Enhance your control panels and outdoor equipment with the high-quality Apem LED Indicator from the Q-Series. Featuring IP67 sealing, it withstands harsh environments while providing bright, reliable illumination in various colors including red, green, yellow, blue, and white. Suitable for 12VDC systems and designed for easy mounting with solder lug or wire terminations, this indicator offers long-lasting performance with a life expectancy of 100,000 hours. Perfect for industrial, outdoor, and instrumentation applications, ensuring visibility and durability in all conditions.
Order your Apem Series Q14 LED Indicator with IP67 waterproof sealing today and give your projects the durable, bright lighting solution they deserve.
Frequently Asked Questions
Where can I buy Apem Q14P1CXXW12E?
You can click on the BUY or RFQ button to purchase Q14P1CXXW12E from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part Q14P1CXXW12E?
You can download the Q14P1CXXW12E datasheet or visit the Apem website for support.
Who is the manufacturer of Q14P1CXXW12E?
Apem
