Apem Q22F5AGXXSG220E Panel Mount LED Indicator
The Q22F5AGXXSG220E is a 22mm panel mount LED indicator designed for industrial and electronic applications. It features a bright chrome finish bezel, epoxy wire terminals, and options for various illumination colors including green with a 95 mcd intensity. The LED operates within a voltage range of 21.6 to 26.4VDC at 40mA, with a viewing angle of 30-100°. Its robust construction supports operation from -40°C to +85°C, and it includes options for IP67 sealing, making it suitable for harsh environments. Custom engraving and sealed options are also available for specialized use.
Apem Q22F5AGXXSG220E Panel Mount LED Indicator Specifications:
- Diameter: 22mm
- Bezel Finish: Bright chrome, black chrome, satin grey, stainless steel, anodized aluminum
- Lens Type: Epoxy diffused or super bright LEDs
- Operating Voltage: 21.6 to 26.4VDC (typical 24VDC)
- Operating Current: 40mA max
- Voltage Range: 3.3 to 99VDC / 12VDC / 24VDC / 28VDC / 110VAC / 220VAC
- Viewing Angle: 30-100°
- Forward Voltage: 3.3V (White), 5.7V (Red), 6.0V (Green), 5.9V (Yellow), 9.9V (Blue)
- Luminous Intensity: 465mcd (Red), 245mcd (Green), 365mcd (Yellow), 120mcd (Blue), 1000mcd (White)
- Sealing: IP67 (optional)
- Temperature Range: -40°C to +85°C
- Lifespan: 100,000 hours
- Material: ABS plastic bezel, epoxy lens
- Termination: Solder lug, fastons, rear epoxy wires, pin options
- Maximum panel thickness: 12mm (prominent bezel), 10mm (flush bezel)
Buy the Buy APEM Panel Mount LED Indicator Part Number Q22F5AGXXSG220E Online
Purchase your APEM Panel Mount LED Indicator Q22F5AGXXSG220E online today. Featuring a durable bright chrome bezel, epoxy diffused lens options, and wide voltage compatibility, it's perfect for industrial control panels. Supports sealing up to IP67 for harsh environments, offers multiple mounting options, and customizable engraving for specific applications. Its robust construction ensures a lifespan of 100,000 hours, making it an excellent choice for reliable visual indication in demanding settings. Get yours now to ensure optimal visibility and performance in your project.
Order your APEM Panel Mount LED Indicator Q22F5AGXXSG220E today and enhance your project with reliable, high-visibility illumination options.
Frequently Asked Questions
Where can I buy Apem Q22F5AGXXSG220E?
You can click on the BUY or RFQ button to purchase Q22F5AGXXSG220E from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part Q22F5AGXXSG220E?
You can download the Q22F5AGXXSG220E datasheet or visit the Apem website for support.
Who is the manufacturer of Q22F5AGXXSG220E?
Apem
