Apem Q8P1CZZRYG24E LED Indicator
This 8mm panel mount LED indicator features a prominent tri-color bezel with red, green, and yellow LEDs, IP67 sealing for protection against dust and water, and a bright chrome finish. Designed for industrial control panels, it operates at 24V DC or AC with a lifespan of 100,000 hours, offering reliable visual signaling. The device includes a sealed bezel, various mounting options, and multiple terminal configurations for ease of installation. Suitable for applications requiring clear, durable, and versatile LED indicators in harsh environments.
Apem Q8P1CZZRYG24E LED Indicator Specifications:
- Size: 8mm panel mount
- Bezel Finish: Bright chrome, black chrome, satin grey
- LED Colors: Red, green, yellow, blue, white, orange, bi-color, tri-color
- Voltage Range: 2VDC - 220VAC (varies by model)
- Sealing: IP67 waterproof protection
- Operating Voltage: 24VDC/AC, others available
- Lifespan: 100,000 hours
- Operating Temperature: -40 to +85°C
- Viewing Angle: 30-100° (dependant on model)
- Max Reverse Voltage: 5V
- Current: 20mA
- Panel Cutout: 8mm
- Terminals: Solder lug, fastons, pins, wire (200mm)
- Material: Brass bezel, epoxy lens
- Forward Voltage: Red 2.0V, Green 2.2V, Yellow 2.1V, Blue 3.3V, White 3.3V, Orange 2.2V
- IP Rating: IP67
Buy the APEM Q8P1CZZRYG24E – Reliable Tri-Color LED Indicator for Industrial Applications
Order the APEM LED Indicator now and enhance your control system with a reliable, durable 8mm tri-color LED indicator. Designed for harsh environments, it features IP67 waterproof sealing and an attractive bright chrome finish. Perfect for industrial and control panel applications, this indicator offers versatile mounting options, long life expectancy of 100,000 hours, and operation at 24V. Easy to install with multiple terminal configurations, it provides clear visual signals. Purchase online today for fast delivery and optimal performance in demanding industrial settings.
Get APEM Q8P1CZZRYG24E today—built for durability with IP67 sealing and versatile terminal options for industrial control panels.
Frequently Asked Questions
Where can I buy Apem Q8P1CZZRYG24E?
You can click on the BUY or RFQ button to purchase Q8P1CZZRYG24E from an authorized Apem distributor.
How do I troubleshoot issues or seek technical support for part Q8P1CZZRYG24E?
You can download the Q8P1CZZRYG24E datasheet or visit the Apem website for support.
Who is the manufacturer of Q8P1CZZRYG24E?
Apem
