Arcolectric - Bulgin MPI005RTELAAM12 Vandal Resistant Switch
This 19mm stainless steel illuminated vandal-resistant switch features a low-profile design with a 22mm bezel diameter and a 19.2mm + 0.2mm fixing hole. Made from durable stainless steel and brass, it offers IP65 sealing with options for IP67, and operates within -25°C to +55°C. The switch supports momentary and latching types with max ratings up to 5A at 12VDC, 24VDC, and 125VAC. It ensures reliable operation with a minimum of 1,000,000 mechanical and 50,000 electrical operations, making it ideal for harsh environments.
Arcolectric - Bulgin MPI005RTELAAM12 Vandal Resistant Switch Specifications:
- Bezel Diameter: 22mm
- Fixing Hole Diameter: 19.2mm + 0.2mm
- Material: Stainless Steel, Brass (Gold Plated) for contacts, Polycarbonate molding
- Switching Types: S.P.C.O Momentary and Latching
- Sealing: IP65, optional IP67
- Max Ratings: 5A @ 12VDC/24VDC, 5A @ 125VAC, 3A @ 250VAC
- Electrical Resistance: Max 1A, 2V contact resistance
- Insulation Resistance: >1000 MQ @ 500V
- Dielectric Strength: > 2.0kVac
- Operating Temp Range: -25°C to +55°C
- Mechanical Operations: Min 1,000,000
- Electrical Operations: Min 50,000
- Materials: Stainless Steel, Aluminum Alloy, Brass, Gold Plated Contacts
- Termination Options: Screw Terminal, Pin Terminal
- Sealing Standard: IP65, IP67 upon request
- Dimensions: Bezel diameter 22mm, fixing hole 19.2mm + 0.2mm
Buy the Buy Stainless Steel Illuminated Vandal Resistant Switch Part Number MPI005RTELAAM12 Online
Purchase the stainless steel vandal-resistant switch online and enjoy secure sealing, durable construction, and reliable performance for industrial applications. With IP65/IP67 sealing options, high current ratings, and a robust stainless steel body, this switch is suitable for harsh environments requiring vandal resistance. Its compact size with a 22mm bezel diameter makes installation flexible while maintaining a sleek appearance. Perfect for controlling equipment in demanding settings, this switch combines durability and performance to support your security and control needs effectively.
Get Stainless Steel Illuminated Vandal Resistant Switch MPI005RTELAAM12 today—designed for durability, secure sealing, and reliable operation in harsh environments.
Frequently Asked Questions
Where can I buy Arcolectric - Bulgin MPI005RTELAAM12?
You can click on the BUY or RFQ button to purchase MPI005RTELAAM12 from an authorized Arcolectric - Bulgin distributor.
How do I troubleshoot issues or seek technical support for part MPI005RTELAAM12?
You can download the MPI005RTELAAM12 datasheet or visit the Arcolectric - Bulgin website for support.
Who is the manufacturer of MPI005RTELAAM12?
Arcolectric - Bulgin
