Bourns 4608X102682LF Thick Film Conformal SIP Resistor
Bourns 4608X-102-682LF thick film conformal SIP resistors are designed for applications requiring compact size and reliable performance. These resistors offer a wide range of resistance values, low profile compatibility with DIPs, and are RoHS compliant. They are available in various pin configurations and packaging options, including Ammo-pak, making them suitable for automated assembly processes. The resistors are marked for permanent identification and are recommended for rosin flux and no-clean flux processes.
Bourns 4608X102682LF Thick Film Conformal SIP Resistor Specifications:
- Resistance Range: 10 ohms to 10 megohms
- Maximum Operating Voltage: 100 V
- Temperature Coefficient of Resistance: ±100 ppm/°C (below 50 Ω), ±250 ppm/°C (above 2.2 megohms)
- Resistance Tolerance: See circuits
- Insulation Resistance: 10,000 megohms minimum
- Dielectric Withstanding Voltage: 200 VRMS
- Operating Temperature: -55 °C to +125 °C
- Short Time Overload: ±0.25 %
- Load Life: ±1.00 %
- Moisture Resistance: ±0.50 %
- Resistance to Soldering Heat: ±0.50 %
- Terminal Strength: ±0.25 %
- Thermal Shock: ±0.25 %
- Flammability: Conforms to UL94V-0
- Body Material: Epoxy resin
- Standard Packaging: Bulk, Ammo-pak available
- Pin Configuration (X): Thick Film Low Profile
- Electrical Configuration (102): Isolated
- Resistance Code: First 2 digits are significant, third digit represents the number of zeros to follow
