BUD INDUSTRIES PN1332AMB Polycarbonate Waterproof Enclosure
The PN1332AMB is a durable, outdoor-rated IP68 NEMA 6P enclosure crafted from polycarbonate with a light gray body and clear cover. Designed for versatile mounting with external wall holes and internal guide slots, it supports vertical and horizontal PCB mounting and terminal connections. The enclosure features stainless steel screws, silicone gasket, UV resistance, and a wide temperature range of -40°C to 120°C, making it suitable for automation, controls, and outdoor internet applications. It complies with UL, RoHS, and IP68 standards, ensuring reliable outdoor protection for electronic equipment.
BUD INDUSTRIES PN1332AMB Polycarbonate Waterproof Enclosure Specifications:
- Material: Polycarbonate
- Color: Light Gray body / Clear cover
- Flammability Rating: UL94-HB
- Ingress Protection: IP68 of IEC 529
- NEMA Ratings: 6P, 1, 2, 3, 4, 4x, 6, 12, 13
- External Dimensions: Length 6.30 in, Width 3.15 in, Depth 2.17 in
- Internal Dimensions: Length 6.06 in, Width 2.91 in, Height 1.93 in
- Wall Mounting Holes: Outside sealing area
- Cover Screws: Stainless steel, non-magnetic
- Gasket Material: Molded Silicon
- Temperature Range: -40°C to 120°C
- Service Temperature Min: -40°C
- Service Temperature Max: 120°C
- Certifications: UL Listed, RoHS Compliant
- UV Stability: Yes, suitable for outdoor use
Buy the Budind Series PN1332 Enclosure: IP68 Polycarbonate Waterproof Box
Protect your electronic equipment with the Budind Series PN1332 waterproof enclosure, designed for outdoor use and IP68 rated for complete dust and water ingress protection. Constructed from durable polycarbonate, it features a clear cover, stainless steel screws, and a molded silicon gasket for a secure seal. Suitable for automation, control systems, and outdoor internet applications, it withstands harsh environments from -40°C to 120°C. Easy to install with external mounting holes and internal guide slots, providing versatile mounting options for PCBs and connectors.
Order your Budind Series PN1332 waterproof enclosure today and ensure reliable outdoor protection for your electronic projects with premium IP68 rated quality.
Frequently Asked Questions
Where can I buy BUD INDUSTRIES PN1332AMB?
You can click on the BUY or RFQ button to purchase PN1332AMB from an authorized BUD INDUSTRIES distributor.
How do I troubleshoot issues or seek technical support for part PN1332AMB?
You can download the PN1332AMB datasheet or visit the BUD INDUSTRIES website for support.
Who is the manufacturer of PN1332AMB?
BUD INDUSTRIES
