BELDEN 1521A0101000 RGB Video Coax Cable
The RGB Video Coax cable is designed for indoor applications, featuring CL2 rating, stranded tinned copper conductors, foam HDPE insulation, Duofoil® and Beldfoil® shields, and PVC jackets. It offers impedance of 75 ohms, capacitance of 17.3 pF across conductors and shield, and a temperature operating range of -40°C to +60°C, making it ideal for high-quality video signal transmission in various indoor environments. The cable complies with multiple international safety standards including UL Style 1354 and 2688, and EU directives on environmental compliance.
BELDEN 1521A0101000 RGB Video Coax Cable Specifications:
- Impedance: 75 Ohm
- Conductor Material: Stranded Tinned Copper
- Insulation: Foam HDPE, 0.056 in thickness
- Outer Jacket Material: PVC, 0.31 in thick
- Shielding: Duofoil® + Beldfoil® shield, overall PVC jackets
- Capacitance: 17.3 pF
- Temperature Range: -40°C to +60°C
- Operating Voltage: 300 VRMS
- Environmental Space: Indoor only
- Standards: UL Style 1354 and 2688, NEC CL2, CPR Eca, compliant with EU RoHS, WEEE, ELV, BFR, Prop 65
- Cable Weight: 55 lbs per 1000 ft, Max Pulling Tension: 56 lbs, Min Bend Radius: 3 inches
- Applicable Connectors: Kings #2025-57-9
Buy the Buy Belden RGB Video Part Number 1521A Online
Order the Belden RGB Video coax cable online today for indoor video signal transmission—featuring CL2 rating, 75 ohms impedance, and durable shielding. Designed for high-performance applications, its stranded tinned copper conductors, foam HDPE insulation, and PVC jackets ensure excellent signal quality and safety compliance. Ideal for professional AV installations, this cable supports UL, EU, and RoHS standards, offering reliability in various environments. Purchase now to experience superior image clarity, excellent shielding, and easy installation, backed by Belden’s proven quality and international safety certifications.
Buy Belden 1521A RGB Video coax cable now and enjoy reliable high-definition video signal transmission indoors with durable shielding and compliance with safety standards.
