BELDEN 29500F0101000 VFD Power Cable
Belden 29500F is a highly flexible, 3-conductor VFD cable designed for smooth and reliable operation in motor and drive systems. Made with tinned copper conductors and XLPE insulation, it offers excellent resistance to high flex, motion, and abrasion. The cable features a black TPE outer jacket, UV and oil resistance, and complies with UL, NEC, and EU standards. Suitable for indoor and outdoor applications, including high vibration environments, it ensures safe, durable, and efficient power transmission for industrial and commercial use.
BELDEN 29500F0101000 VFD Power Cable Specifications:
- Conductor Material: Tinned Copper
- Insulation: XLPE (Cross-Linked Polyethylene), 0.046in
- Ground Material: PVC, 0.046in, Green/Yellow stripe
- Outer Shield: Tri-Laminate Tape + Braid (Alum+Poly+Alum) + Tinned Copper (85%)
- Outer Jacket: TPE, 0.063in, 0.528in diameter
- Cable Diameter: 0.528 inches
- Voltage Rating: 1000 V (TC, WTTC), 600 V (CIC TC)
- Temperature Range: -40°C to +90°C, 90°C (Dry & Wet)
- Standards & Compliance: UL1685, FT4, UL Flexible Motor Supply, NEC Article 336, IEC, EU CE Mark, WEEE, China RoHS
- Environmental Resistance: Sunlight, Oil, Burial, Indoor & Outdoor
- Sustainability: CA Prop 65
Buy the Belden Series VFD Power Cable: 29500F
Purchase the Belden 29500F VFD power cable online today to ensure seamless power delivery in variable frequency drive applications. Designed with XLPE insulation and a TPE jacket, this cable withstands harsh environments, UV exposure, and high flex demands. Its construction features tinned copper conductors, a tri-laminate shield, and compliance with UL, NEC, and international standards for safety and durability. Ideal for outdoor, indoor, and industrial installations, it provides excellent resistance to oil, sunlight, abrasion, and moisture, making it the ideal choice for reliable motor and drive system connections.
Get Belden 29500F today—built for high flexibility, reliable power transmission, and durable outdoor performance.
Frequently Asked Questions
Where can I buy BELDEN 29500F0101000?
You can click on the BUY or RFQ button to purchase 29500F0101000 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 29500F0101000?
You can download the 29500F0101000 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 29500F0101000?
BELDEN
