BELDEN 73603W008100 Flexible Multi-Conductor Cable
The 73603W multi-conductor cable is designed for unshielded, light to moderate flexing applications up to 1 million flex cycles, rated at 600V. It consists of 16 AWG stranded bare copper conductors with PVC insulation and oil-resistant PVC jacket, offering flexibility and durability for industrial wiring. The cable features a total diameter of 0.300 inches, a weight of 106 lbs per 1000 ft, and complies with UL 2587 and CSA standards. Suitable for burial, with excellent flame and oil resistance for reliable electrical performance in demanding environments.
BELDEN 73603W008100 Flexible Multi-Conductor Cable Specifications:
- Conductors: 16 AWG stranded (26x30) bare copper
- Insulation Material: PVC
- Outer Jacket Material: Oil-resistant PVC
- Overall Diameter: 0.300 in.
- Weight: 106 lbs/1000 ft
- Maximum Pulling Tension: 61 lbs.
- Minimum Bend Radius: 1.500 in.
- Flex Cycle Rating: 1 million cycles
- Storage Temperature Range: -40°C to +90°C
- Installation Temperature Range: -8°C to +90°C
- UL Rating: UL 2587 (600 V)
- CSA Rating: CSA 600 V
- Flame Test: CSA FT
- Conductor Resistance: Specified by manufacturer
- Capacitance: Max conductor to conductor unspecified
- Applicable Standards: UL, CSA, EU RoHS, VDE 0472, REACH, California Proposition 65
- Suitable for burial applications, oil-resistant, flame tested, excellent for flexible industrial wiring
Buy the Buy Belden Flexible Multi-Conductor Cable Part Number 73603W008100 Online
Secure your wiring projects with Belden 73603W flexible multi-conductor cable, rated for 600V with oil-resistant PVC jacket and stranded copper conductors. Perfect for industrial, burial, and flexible applications, this cable guarantees durability, flexibility, and safety. With a robust design supporting up to 1 million flex cycles, it is ideal for demanding electrical environments. Buy online now to enjoy fast delivery and reliable performance in all your electrical installations. Trust Belden for quality and dependability.
Order your Belden 73603W Series flexible multi-conductor cable today and ensure your industrial wiring projects are equipped with durable, high-quality cables designed for demanding environments.
Frequently Asked Questions
Where can I buy BELDEN 73603W008100?
You can click on the BUY or RFQ button to purchase 73603W008100 from an authorized BELDEN distributor.
How do I troubleshoot issues or seek technical support for part 73603W008100?
You can download the 73603W008100 datasheet or visit the BELDEN website for support.
Who is the manufacturer of 73603W008100?
BELDEN
